Release Notes for Cisco  IOS  Release  11.1

Release Notes for Cisco  IOS  Release  11.1

January 11, 1999

These release notes describe the features and caveats for Cisco  IOS Release  11.1 up to and including Release  11.1(24). They include all routing and access server features.

Introduction

These release notes discuss the following topics:

Documentation

Cisco  IOS Release  11.1 access server and router software functionality and configuration information is documented in a six-module documentation set. (Previous to Release 11.1, access server software and router software were documented separately.) Each module consists of a configuration guide and a command reference. There are also five supporting documents.

The six documentation modules and supporting documents cover these topics:

Books Chapter Topics

· Configuration Fundamentals Configuration Guide

· Configuration Fundamentals Command Reference

Access Server and Router Product Overview

User Interface

Loading System Images and Configuration Files

Setup Command

Interfaces

System Management

· Access Services Configuration Guide

· Access Services Command Reference

Terminal Lines and Modem Support

AppleTalk Remote Access

SLIP and PPP

XRemote

LAT

Telnet

TN3270

Protocol Translation

· Wide-Area Networking Configuration Guide

· Wide-Area Networking Command Reference

ATM

Dial-on-Demand Routing (DDR)

Frame Relay

ISDN

LANE

SMDS

X.25

· Network Protocols Configuration Guide, Part 1

· Network Protocols Command Reference, Part 1

AppleTalk

IP

IP Routing

Novell IPX

· Network Protocols Configuration Guide, Part 2

· Network Protocols Command Reference, Part 2

Apollo Domain

Banyan VINES

DECnet

ISO CLNS

XNS

· Bridging and IBM Networking Configuration Guide

· Bridging and IBM Networking Command Reference

Transparent Bridging

Source-Route Bridging

Remote Source-Route Bridging

DLSw+

STUN and BSTUN

LLC2 and SDLC

IBM Network Media Translation

DSPU and SNA Service Point Support

SNA Frame Relay Access Support

APPN

IBM Channel Attach

· Cisco  IOS Software Command Summary

· Cisco Management Information Base (MIB) User Quick Reference

· System Error Messages

· Debug Command Reference

· Cisco Access Connection Guide

(Supporting Documents)

These documents are available both as printed manuals and as electronic documents. The most up-to-date Cisco IOS documentation can be found on the latest Documentation CD-ROM and on the Web. The electronic documents contain updates and modifications made after the paper documents were printed.

You can access the electronic documents either on the Cisco Documentation CD-ROM or at Cisco Connection Online (CCO) on the World Wide Web.

On the CD-ROM, go to the Cisco  IOS Software Configuration database, select Cisco  IOS Release  11.1, and follow the link to the Cisco  IOS Configuration Guides and Command References.

CCO is on the World Wide Web at http://www.cisco.com, http://www-europe.cisco.com, or http://www-china.cisco.com. From CCO, go to the Technical Documentation page to find the Cisco  IOS Software Configuration database. Then, select Cisco  IOS Release  11.1, and follow the link to the Cisco  IOS Configuration Guides and Command References.

Additional information about CCO and the Documentation CD-ROM is in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of these release notes.

Platform Support

You can run all Cisco  IOS 11.1 releases on these Cisco hardware platforms, except as noted:

For each of the supported platforms, Release  11.1 enables your Cisco device to use certain LAN and WAN interfaces and data rates.

For a list of interfaces supported by Release  11.1 for each platform, see Table 1, Table 2, Table 3, and Table 4 (following).

For each platform, you can use any of the interfaces or data rates labeled "Yes" in the table. Release  11.1 does not support interfaces or data rates that are labeled "No."


Table 1: LAN Interfaces Supported by Router Platforms, Part 1
Interface Cisco 7500 Series Cisco 7200 Series Cisco 7000 Series Cisco 4000 Series Cisco 3000 Series1 Cisco 2500 Series

Ethernet (AUI)

Yes

Yes

Yes

Yes

Yes

Yes

Ethernet (10BaseT)

Yes

Yes

Yes

Yes

No

Yes2

Ethernet (10BaseFL)

Yes

Yes

Yes3

No

No

No

Fast Ethernet (100BaseTX)

Yes

Yes

Yes3

Yes4

No

No

Fast Ethernet (100BaseFX)

Yes

Yes

Yes

Yes4

No

No

4-Mbps Token Ring

Yes

Yes

Yes

Yes

Yes

Yes

16-Mbps Token Ring

Yes

Yes

Yes

Yes

Yes

Yes

FDDI DAS

Yes

Yes

Yes

Yes

No

No

FDDI SAS

Yes

No

Yes

Yes

No

No

FDDI multimode

Yes

Yes

Yes

Yes (DAS/
SAS)

No

No

FDDI single-mode

Yes

Yes

Yes

Yes

No

No

ATM Interface

Yes

No

Yes

Yes

No

No

Channel Interface

Yes

No

Yes

No

No

No

Second-generation Channel Interface5

Yes

No

Yes

No

No

No

Parallel Channel Adapter (Bus and Tag)

Yes

No

Yes

No

No

No

ESCON Channel Adapter (ECA)

Yes

No

Yes

No

No

No

Versatile Interface

Yes

No

Yes

No

No

No

Second-generation Versatile Interface2

Yes

No

Yes

No

No

No

MultiChannel Interface (Channelized E1/T1)

Yes

No

Yes

Yes

No

No

Packet-Over-SONET OC-3 Interface2

Yes

No

Yes

Yes

No

No

Synchronous Serial

Yes

Yes

Yes

Yes

Yes

Yes

1Except the Cisco 3202.
2Cisco  2505, Cisco  2507, Cisco  2516, Cisco  2518, and Cisco  2520-Cisco  2525 only.
3May require the 7000 series Route Switch Processor (RSP7000).
4Only the Cisco 4500, 4500-M, 4700, and 4700-M routers support Fast Ethernet.
5In the Cisco 7000 series routers (Cisco 7000 and Cisco 7010), these interfaces require either a Route Processor (RP) and Switch Processor (SP) (or Silicon Switch Processor [SSP]) combination, or a combination of the 7000 series Route Switch Processor (RSP7000) and the 7000 series chassis interface (RSP7000CI).


Table 2: LAN Interfaces Supported by Router Platforms, Part 2
Interface Cisco 1003/
1004 		Cisco 1005 Cisco 1000 LAN Extender AccessPro
PC Card 		Cisco AS5100 Cisco AS5200

Ethernet (AUI)

No

No

Yes

No

Yes

Yes

Ethernet (10BaseT)

Yes

Yes

Yes

Yes

No

No

Ethernet (10BaseFL)

No

No

No

No

No

No

Fast Ethernet (100BaseTX)

No

No

No

No

No

No

Fast Ethernet (100BaseFX)

No

No

No

No

No

No

4-Mbps Token Ring

No

No

No

Yes

No

No

16-Mbps Token Ring

No

No

No

Yes

No

No

FDDI DAS

No

No

No

No

No

No

FDDI SAS

No

No

No

No

No

No

FDDI multimode

No

No

No

No

No

No

FDDI single-mode

No

No

No

No

No

No

ATM Interface

No

No

No

No

No

No

Channel Interface

No

No

No

No

No

No

Second-generation Channel Interface

No

No

No

No

No

No

Parallel Channel Adapter (Bus and Tag)

No

No

No

No

No

No

ESCON Channel Adapter (ECA)

No

No

No

No

No

No

Versatile Interface

No

No

No

No

No

No

Second-generation Versatile Interface

No

No

No

No

No

No

MultiChannel Interface (Channelized E1/T1)

No

No

No

No

No

Yes

Packet-Over-SONET OC-3 Interface

No

No

No

No

No

No

Synchronous Serial

No

No

No

No

Yes

Yes


Table 3: WAN Data Rates and Interfaces Supported by Router Platforms, Part 1
Cisco 7500 Series Cisco 7200 Series Cisco 7000 Series Cisco 4000 Series Cisco 3000 Series1 Cisco 2500 Series
Data Rate

48/56/64 kbps

Yes

Yes

Yes

Yes

Yes

Yes

1.544/2.048 Mbps

Yes

Yes

Yes

Yes

Yes

Yes

34/45/52 Mbps

Yes

Yes

Yes

No

No

No

Interface

EIA/TIA-232

Yes

Yes

Yes

Yes

Yes

Yes

X.21

Yes

Yes

Yes

Yes

Yes

Yes

V.35

Yes

Yes

Yes

Yes

Yes

Yes

EIA/TIA-449

Yes

Yes

Yes

Yes

Yes

Yes

EIA-530

Yes

Yes

Yes

Yes

Yes

Yes

EIA/TIA-613 (HSSI)

Yes

No

Yes

No

No

No

ISDN BRI

No

No

No

Yes

Yes

Yes

ISDN PRI

Yes

No

Yes

Yes

No

No

E1-G.703/G.704

Yes

No

Yes

Yes

No

No

1Except the Cisco 3202


Table 4: WAN Data Rates and Interfaces Supported by Router Platforms, Part 2
Cisco 1003/
1004 		Cisco 1005 Cisco 1000 LAN Extender AccessPro PC Card Cisco AS5100 Cisco AS5200
Data Rate

48/56/64 kbps

Yes

Yes

Yes

Yes

Yes

Yes

1.544/2.048 Mbps

No

Yes

Yes

Yes

Yes

Yes

34/45/52 Mbps

No

No

No

No

No

No

Interface

EIA/TIA-232

No

Yes

No

Yes

Yes

Yes

X.21

No

Yes

Yes

Yes

Yes

Yes

V.35

No

Yes

Yes

Yes

Yes

Yes

EIA/TIA-449

No

Yes

No

Yes

Yes

Yes

EIA-530

No

Yes

No

Yes

Yes

Yes

EIA/TIA-613 (HSSI)

No

No

No

No

No

No

ISDN BRI

Yes

Yes

No

Yes

No

No

ISDN PRI

No

No

No

No

No

Yes

E1-G.703/G.704

No

No

No

No

No

Yes

Cisco  IOS Packaging

The Cisco  IOS software is packaged into "feature sets" (also called "software images"). There are many different feature sets available, and each feature set contains a specific subset of Cisco  IOS features. Not all feature sets are available with all platforms. Also, some feature sets support different features when run on different platforms.

To learn what features are available with each feature set, see tables Table 5 through Table 14 (following). These tables summarize what features you can use when running a specific feature set on a specific platform. A "Yes" in the table indicates that the feature is available in the feature set.

You can use these tables to determine if you can configure and use a specific feature with your platform and Release  11.1 feature set.

Note For some platforms, you can purchase a "feature pack," which contains a group of one or more feature sets on a CD-ROM. For more information about feature packs, refer to the release notes for Cisco  IOS Release  11.1  feature packs, or refer to the Feature Pack Information web page on CCO or the Documentation CD-ROM in the Cisco  IOS Release  11.1 documentation area.


Table 5: Cisco 7500 Series Software Feature Sets
Feature Feature Set
IP IP/IPX/
IBM 		IP/IPX/
IBM/
APPN 		Desktop/
IBM 		Enter-
prise 		Enter-
prise/
APPN 		IP/VIP IP/IPX/
IBM/
VIP 		IP/IPX/
IBM/
APPN/VIP 		Desktop/IBM/VIP Enter-
prise/
VIP 		Enter-
prise/
APPN/
VIP

SNMP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RMON (events and alarms)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Asynchronous support (SLIP)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Frame Relay

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

SMDS

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

X.25

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

ISDN

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PPP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

HDLC

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIPv2

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IGRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Enhanced IGRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

OSPF

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

BGP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

EGP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PIM

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NHRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

ES-IS

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IS-IS

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Snapshot routing

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NTP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Transparent bridging

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Translational bridging

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Multiring

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

LAN extension host

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IPX

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

NLSP

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

IPXWAN 2.0

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

AppleTalk Versions 1
and 2

---

---

---

Yes

Yes

Yes

---

---

---

Yes

Yes

Yes

AURP

---

---

---

Yes

Yes

Yes

---

---

---

Yes

Yes

Yes

DECnet IV

---

---

---

Yes

Yes

Yes

---

---

---

Yes

Yes

Yes

DECnet V

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

Apollo Domain

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

Banyan VINES

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

ISO CLNS

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

XNS

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

Lock-and-Key

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

MD5 routing authentication

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Kerberized login

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

TACACS+

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

RADIUS

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

V.120

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

SRB

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

RSRB

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

APPN

---

---

Yes

---

---

Yes

---

---

---

---

---

Yes

FRAS BAN

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

DLSw (RFC 1795)

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

DLSw+

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

SDLC

---

Yes

Yes

Yes

Yes

Yes

---

---

Yes

---

Yes

Yes

SDLLC

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

SRT bridging

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

STUN

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

TG/COS

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

QLLC

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

DSPU

---

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

NetView Native Service Point

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

Protocol translation

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

Telnet

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PAD

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

AutoInstall

---

---

Yes

Yes

Yes

Yes

---

---

Yes

Yes

Yes

Yes

Router monitoring

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

High System Availability (HSA)

---

---

---

---

---

---

Yes

Yes

Yes

Yes

Yes

Yes

DHCP

---

---

---

---

Yes

Yes

---

---

---

---

Yes

Yes

NetBEUI over PPP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes




Table 6: Cisco 7200 Series Software Feature Sets
Feature Feature Set
Network Layer 3 Switching Desktop/IBM Enterprise Enterprise/APPN

SNMP

Yes

Yes

Yes

Yes

RMON (events and alarms)

Yes

Yes

Yes

Yes

Asynchronous support (SLIP)

Yes

Yes

Yes

Yes

Frame Relay

---

Yes

Yes

Yes

SMDS

Yes

Yes

Yes

Yes

X.25

Yes

Yes

Yes

Yes

ISDN

---

Yes

Yes

Yes

PPP

---

Yes

Yes

Yes

HDLC

---

Yes

Yes

Yes

IP

Yes

Yes

Yes

Yes

RIP

Yes

Yes

Yes

Yes

RIPv2

Yes

Yes

Yes

Yes

IGRP

Yes

Yes

Yes

Yes

Enhanced IGRP

Yes

Yes

Yes

Yes

OSPF

Yes

Yes

Yes

Yes

BGP

Yes

Yes

Yes

Yes

EGP

Yes

Yes

Yes

Yes

PIM

Yes

Yes

Yes

Yes

NHRP

Yes

Yes

Yes

Yes

Policy-based routing

Yes

Yes

Yes

Yes

ES-IS

---

---

Yes

Yes

IS-IS

---

---

Yes

Yes

DDR

---

Yes

Yes

Yes

Snapshot routing

---

Yes

Yes

Yes

NTP

Yes

Yes

Yes

Yes

Transparent bridging

Yes

Yes

Yes

Yes

Translational bridging

Yes

Yes

Yes

Yes

Concurrent routing and bridging

Yes

Yes

Yes

Yes

Multiring

Yes

Yes

Yes

Yes

LAN extension host

Yes

Yes

Yes

Yes

ISL

Yes

---

---

---

GRE

---

Yes

Yes

Yes

IPX

Yes

Yes

Yes

Yes

NLSP

Yes

Yes

Yes

Yes

IPX RIP

Yes

Yes

Yes

Yes

RTMP

Yes

Yes

Yes

Yes

IPXWAN 2.0

---

Yes

Yes

Yes

AppleTalk Versions 1
and 2

---

Yes

Yes

Yes

AURP

Yes

Yes

Yes

Yes

SMRP

Yes

Yes

Yes

Yes

SRTP

---

---

Yes

Yes

DECnet IV

---

Yes

Yes

Yes

DECnet V

---

---

Yes

Yes

OSI

---

---

Yes

Yes

Apollo Domain

---

---

Yes

Yes

Banyan VINES

---

---

Yes

Yes

ISO CLNS

---

---

Yes

Yes

XNS

---

---

Yes

Yes

Lock-and-Key

Yes

Yes

Yes

Yes

MD5 routing authentication

Yes

Yes

Yes

Yes

Kerberized login

---

---

Yes

Yes

TACACS+

Yes

Yes

Yes

Yes

RADIUS

Yes

Yes

Yes

Yes

V.120

---

---

Yes

Yes

SRB1

---

Yes

Yes

Yes

RSRB

---

Yes

Yes

Yes

APPN

---

---

---

Yes

FRAS BAN

---

Yes

Yes

Yes

DLSw (RFC 1795)

---

Yes

Yes

Yes

DLSw+2

---

Yes

Yes

Yes

SDLC

---

Yes

Yes

Yes

SDLLC

---

Yes

Yes

Yes

SRT bridging

---

Yes

Yes

Yes

STUN

---

Yes

Yes

Yes

TG/COS

---

---

Yes

Yes

QLLC

---

Yes

Yes

Yes

DSPU

---

---

Yes

Yes

NetView Native Service Point

---

Yes

Yes

Yes

Protocol translation

---

---

Yes

Yes

Telnet

Yes

Yes

Yes

Yes

Modem auto-configuring

Yes

Yes

Yes

Yes

PAD

---

---

Yes

Yes

AutoInstall

Yes

Yes

Yes

Yes

Router monitoring

---

---

Yes

Yes

DHCP

---

---

Yes

Yes

NetBEUI over PPP

---

---

Yes

Yes

1SRB over FDDI is not supported in this release.
2DLSw+ over TCP/IP is supported.



Table 7: Cisco 7000 Series Software Feature Sets
Feature Feature Set
IP IP/IPX/
IBM 		IP/IPX/
IBM/
APPN 		Desk-
top/
IBM 		Enter-
prise 		Source-
Route
Switch 		Enter-
prise/
APPN 		IP/
VIP 		IP/
IPX/
IBM/
VIP 		IP/IPX/
IBM/
APPN/VIP 		Desk-
top/
IBM/
VIP 		Enter-
prise/
VIP 		Enter-
prise/
APPN/
VIP

SNMP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RMON (events and alarms)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Asynchronoussupport (SLIP)

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Frame Relay

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

SMDS

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

X.25

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

ISDN

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PPP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

HDLC

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IP

Yes

Yes

Yes

Yes

Yes

Yes (host only)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIPv2

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IGRP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Enhanced IGRP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

OSPF

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

BGP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

EGP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PIM

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NHRP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

ES-IS

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IS-IS

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Snapshot routing

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NTP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Transparent bridging

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Translational bridging

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Multiring

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

LAN extension host

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IPX

---

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

Yes

Yes

Yes

NLSP

---

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

Yes

Yes

Yes

IPXWAN 2.0

---

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

Yes

Yes

Yes

AppleTalk Versions 1 and 2

---

---

---

Yes

Yes

---

Yes

---

---

---

Yes

Yes

Yes

AURP

---

---

---

Yes

Yes

---

Yes

---

---

---

Yes

Yes

Yes

DECnet IV

---

---

---

Yes

Yes

---

Yes

---

---

---

Yes

Yes

Yes

DECnet V

---

---

---

---

Yes

---

Yes

---

---

---

---

Yes

Yes

Apollo Domain

---

---

---

---

Yes

---

Yes

---

---

---

---

Yes

Yes

Banyan VINES

---

---

---

---

Yes

---

Yes

---

---

---

---

Yes

Yes

ISO CLNS

---

---

---

---

Yes

---

Yes

---

---

---

---

Yes

Yes

XNS

---

---

---

---

Yes

---

Yes

---

---

---

---

Yes

Yes

Lock-and-
Key

Yes

Yes

Yes

Yes

Yes

Yes

Yes

---

---

---

Yes

Yes

Yes

MD5 routing authentication

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Kerberized login

---

---

---

---

Yes

Yes

Yes

---

---

---

---

Yes

Yes

TACACS+

---

---

---

---

Yes

Yes

Yes

---

---

---

---

Yes

Yes

RADIUS

---

---

---

---

Yes

Yes

Yes

---

---

---

---

Yes

Yes

V.120

---

---

---

---

Yes

Yes

Yes

---

---

---

---

Yes

Yes

SRB

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RSRB

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

APPN

---

---

Yes

---

---

---

Yes

---

---

---

---

---

Yes

FRAS BAN

---

---

---

---

Yes

---

Yes

---

---

---

---

Yes

Yes

DLSw
(RFC 1795)

---

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

Yes

Yes

Yes

DLSw+

---

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

Yes

Yes

Yes

SDLC

---

Yes

Yes

Yes

Yes

---

Yes

---

---

Yes

---

Yes

Yes

SDLLC

---

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

Yes

Yes

Yes

SRT bridging

---

Yes

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

STUN

---

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

Yes

Yes

Yes

TG/COS

---

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

Yes

Yes

Yes

QLLC

---

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

Yes

Yes

Yes

DSPU

---

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

Yes

Yes

Yes

NetView Native Service Point

---

---

---

---

Yes

Yes

Yes

---

---

---

---

Yes

Yes

Protocol translation

---

---

---

---

Yes

Yes

Yes

---

---

---

---

Yes

Yes

Telnet

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PAD

---

---

---

---

Yes

---

Yes

---

---

---

---

Yes

Yes

AutoInstall

---

---

Yes

Yes

Yes

---

Yes

---

---

Yes

Yes

Yes

Yes

Router monitoring

---

---

---

---

Yes

Yes

Yes

---

---

---

---

Yes

Yes

DHCP

---

---

---

---

Yes

---

Yes

---

---

---

---

Yes

Yes

NetBEUI over PPP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes




Table 8: Cisco 2500 Series and AS5100 Software Feature Sets, Part 1
Feature Feature Set
IP IP/RMON IP/IBM
Base 		IP/IBM/
RMON 		IP/IPX IP/IPX/
RMON 		IP/IPX/
IBM Base 		IP/IPX/IBM/RMON IP/IPX/IBM/
APPN

SNMP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RMON1

---

Yes

---

Yes

---

Yes

---

Yes

---

Asynchronous support (SLIP)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

CSLIP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

ARAP

---

---

---

---

---

---

---

---

---

Frame Relay

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

SMDS

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

X.25

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

ISDN

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PPP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

CPPP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

HDLC

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIPv2

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IGRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Enhanced IGRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

OSPF

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

BGP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

EGP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PIM

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NHRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

ES-IS

---

---

---

---

---

---

---

---

---

IS-IS

---

---

---

---

---

---

---

---

---

Snapshot routing

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NTP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Bridging (transparent and translational)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Multiring

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

LAN extension host

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IPX

---

---

---

---

Yes

Yes

Yes

Yes

Yes

NLSP

---

---

---

---

Yes

Yes

Yes

Yes

Yes

IPXWAN 2.0

---

---

---

---

Yes

Yes

Yes

Yes

Yes

RTMP

---

---

---

---

---

---

---

---

---

SMRP

---

---

---

---

---

---

---

---

---

SRTP

---

---

---

---

---

---

---

---

---

AppleTalk Versions 1 and 2

---

---

---

---

---

---

---

---

---

AURP

---

---

---

---

---

---

---

---

---

DECnet IV

---

---

---

---

---

---

---

---

---

DECnet V

---

---

---

---

---

---

---

---

---

Apollo Domain

---

---

---

---

---

---

---

---

---

Banyan VINES

---

---

---

---

---

---

---

---

---

ISO CLNS

---

---

---

---

---

---

---

---

---

XNS

---

---

---

---

---

---

---

---

---

Lock-and-Key

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

MD5 routing authentication

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Kerberized login

---

---

---

---

---

---

---

---

---

V.120

---

---

---

---

---

---

---

---

---

SRB

---

---

Yes

Yes

---

---

Yes

Yes

Yes

RSRB

---

---

Yes

Yes

---

---

Yes

Yes

Yes

APPN

---

---

---

---

---

---

---

---

Yes

FRAS BAN

---

---

Yes

Yes

---

---

Yes

Yes

Yes

DLSw (RFC 1795)

---

---

Yes

Yes

---

---

Yes

Yes

Yes

DLSw+

---

---

Yes

Yes

---

---

Yes

Yes

Yes

SDLC

---

---

Yes

Yes

---

---

Yes

Yes

Yes

SDLLC

---

---

Yes

Yes

---

---

Yes

Yes

Yes

STUN

---

---

Yes

Yes

---

---

Yes

Yes

Yes

TG/COS

---

---

---

---

---

---

---

---

---

QLLC

---

---

Yes

Yes

---

---

Yes

Yes

Yes

Bisync

---

---

Yes

Yes

---

---

Yes

Yes

Yes

DSPU

---

---

---

---

---

---

---

---

---

NetView Native Service Point

---

---

Yes

Yes

---

---

---

Yes

Yes

Protocol translation

---

---

---

---

---

---

---

---

---

TN3270

---

---

---

---

---

---

---

---

---

LAT

---

---

---

---

---

---

---

---

---

SRT Bridging

---

---

Yes

Yes

---

---

Yes

Yes

Yes

XRemote

---

---

---

---

---

---

---

---

---

Telnet

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PAD

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

AutoInstall

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Modem auto- configuring

---

---

---

---

---

---

---

---

---

Router monitoring

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

DHCP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NASI

---

---

---

---

---

---

---

---

---

NetBEUI over PPP

---

---

---

---

---

---

---

---

---

1All feature sets include RMON alarm and events groups. Full, nine-group RMON support is included in the feature sets indicated.


Table 9: Cisco 2500 Series and AS5100 Software Feature Sets, Part 2
Feature Feature Set
Desktop Desktop/
IBM Base 		Enterprise Enterprise/RMON Enterprise/APPN CFRAD Remote Access Server ISDN LAN
FRAD 		OSPF LAN
FRAD1

SNMP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RMON2

---

---

---

Yes

---

---

---

---

---

---

Asynchronous support (SLIP)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

CSLIP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

ARAP

Yes

Yes

Yes

Yes

Yes

---

Yes

---

---

---

Frame Relay

Yes

Yes

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

SMDS

Yes

Yes

Yes

Yes

Yes

---

---

---

---

---

X.25

Yes

Yes

Yes

Yes

Yes

---

Yes

---

---

---

ISDN

Yes

Yes

Yes

Yes

Yes

---

---

Yes

---

---

PPP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

CPPP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

HDLC

Yes

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

IP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIPv2

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IGRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Enhanced IGRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes3

OSPF

Yes

Yes

Yes

Yes

Yes

---

---

Yes

---

Yes

BGP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

---

---

EGP

Yes

Yes

Yes

Yes

Yes

---

---

Yes

---

---

PIM

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

---

---

NHRP

Yes

Yes

Yes

Yes

Yes

---

---

Yes

---

---

ES-IS

---

---

Yes

Yes

Yes

---

---

---

---

---

IS-IS

---

---

Yes

Yes

Yes

---

---

---

---

---

Snapshot routing

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

---

---

NTP

Yes

Yes

Yes

Yes

Yes

---

Yes

---

---

---

Bridging (transparent and translational)

Yes

Yes

Yes

Yes

Yes

---

---

Yes

Yes

Yes

Multiring

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

LAN extension host

Yes

Yes

Yes

Yes

Yes

---

---

---

---

---

IPX

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Yes

Yes

NLSP

Yes

Yes

Yes

Yes

Yes

---

---

---

---

---

IPXWAN 2.0

Yes

Yes

Yes

Yes

Yes

---

Yes

---

Yes

Yes

RTMP

Yes

Yes

Yes

Yes

Yes

---

Yes

---

---

---

SMRP

Yes

Yes

Yes

Yes

Yes

---

Yes

---

---

---

SRTP

---

---

Yes

Yes

Yes

---

Yes

---

---

---

AppleTalk Versions 1 and 2

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

---

---

AURP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

---

---

DECnet IV

Yes

Yes

Yes

Yes

Yes

---

---

---

---

---

DECnet V

---

---

Yes

Yes

Yes

---

---

---

---

---

Apollo Domain

---

---

Yes

Yes

Yes

---

---

---

---

---

Banyan VINES

---

---

Yes

Yes

Yes

---

---

---

---

---

ISO CLNS

---

---

Yes

Yes

Yes

---

---

---

---

---

XNS

---

---

Yes

Yes

Yes

---

---

---

---

---

Lock-and-Key

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

MD5 routing authentication

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Kerberized login

---

---

Yes

Yes

Yes

---

---

---

V.120

---

---

Yes

Yes

Yes

---

---

---

---

---

SRB

---

Yes

Yes

Yes

Yes

---

---

---

Yes

Yes

RSRB

---

Yes

Yes

Yes

Yes

Yes

---

---

Yes

Yes

APPN

---

---

---

---

Yes

---

---

---

---

---

FRAS BAN

---

Yes

Yes

Yes

Yes

Yes

---

---

DLSw
(RFC 1795)

---

Yes

Yes

Yes

Yes

Yes

---

---

Yes

Yes

DLSw+

---

Yes

Yes

Yes

Yes

---

---

---

---

---

SDLC

---

Yes

Yes

Yes

Yes

Yes

---

---

Yes

Yes

SDLLC

---

Yes

Yes

Yes

Yes

Yes

---

---

Yes

Yes

STUN

---

Yes

Yes

Yes

Yes

Yes

---

---

Yes

Yes

TG/COS

---

---

Yes

Yes

Yes

---

---

---

---

---

QLLC

---

Yes

Yes

Yes

Yes

---

---

---

---

---

Bisync

---

Yes

Yes

Yes

Yes

Yes

---

---

Yes

Yes

DSPU

---

---

Yes

Yes

Yes

---

---

---

---

---

NetView Native Service Point

---

Yes

Yes

Yes

Yes

Yes

---

---

Protocol translation

---

---

Yes

Yes

Yes

---

Yes

---

---

---

TN3270

---

---

Yes

Yes

Yes

---

Yes

---

---

---

LAT

---

---

Yes

Yes

Yes

---

Yes

---

---

---

SRT Bridging

---

Yes

Yes

Yes

Yes

---

---

---

XRemote

---

---

Yes

Yes

Yes

---

Yes

---

---

---

Telnet

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PAD

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

---

---

AutoInstall

Yes

Yes

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

Modem auto configuration

---

---

Yes

Yes

Yes

---

Yes

---

---

---

Router monitoring

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

DHCP

Yes

Yes

Yes

Yes

Yes

---

Yes

Yes

---

---

NASI

---

---

---

---

---

---

Yes

---

---

---

NetBEUI over PPP

---

---

Yes

Yes

Yes

---

Yes

---

---

---

1The OSPF LANFRAD feature set is available in Release  11.1(9) and later.
2All feature sets except CFRAD include RMON alarm and events groups. Full, nine-group RMON support is included in the feature sets indicated.
3Enhanced IGRP is only available in Release  11.1(9). It is not supported in any subsequent releases of the Release  11.1 OSPF LANFRAD feature set.


Table 10: Cisco AS5200 Software Feature Sets
Feature Feature Set
IP/Managed Modems Desktop/
Managed Modems 		Enterprise/RMON/
Managed Modems

SNMP

Yes

Yes

Yes

RMON1

---

---

Yes

Asynchronous support (SLIP)

Yes

Yes

Yes

CSLIP

Yes

Yes

Yes

ARA Protocol

---

Yes

Yes

Frame Relay

Yes

Yes

Yes

SMDS

Yes

Yes

Yes

X.25

Yes

Yes

Yes

ISDN

Yes

Yes

Yes

PPP

Yes

Yes

Yes

CPPP

Yes

Yes

Yes

HDLC

Yes

Yes

Yes

IP

Yes

Yes

Yes

RIP

Yes

Yes

Yes

RIPv2

Yes

Yes

Yes

IGRP

Yes

Yes

Yes

Enhanced IGRP

Yes

Yes

Yes

OSPF

Yes

Yes

Yes

BGP

Yes

Yes

Yes

EGP

Yes

Yes

Yes

PIM

Yes

Yes

Yes

NHRP

Yes

Yes

Yes

ES-IS

---

---

Yes

IS-IS

---

---

Yes

Snapshot routing

Yes

Yes

Yes

NTP

Yes

Yes

Yes

Bridging (transparent and translational)

Yes

Yes

Yes

Multiring

Yes

Yes

Yes

LAN extension host

Yes

Yes

Yes

IPX

---

Yes

Yes

NLSP

---

Yes

Yes

IPXWAN 2.0

---

Yes

Yes

RTMP

---

Yes

Yes

SMRP

---

Yes

Yes

SRTP

---

---

Yes

AppleTalk Versions 1 and 2

---

Yes

Yes

AURP

---

Yes

Yes

DECnet IV

---

Yes

Yes

DECnet V

---

---

Yes

Apollo Domain

---

---

Yes

Banyan VINES

---

---

Yes

ISO CLNS

---

---

Yes

XNS

---

---

Yes

Lock-and-Key

Yes

Yes

Yes

MD5 routing authentication

Yes

Yes

Yes

Kerberized login

---

---

Yes

V.120

---

---

Yes

SRB

---

---

Yes

RSRB

---

---

Yes

APPN

---

---

---

FRAS BAN

---

---

Yes

DLSw (RFC 1795)

---

---

Yes

DLSw+

---

---

Yes

SDLC

---

---

Yes

SDLLC

---

---

Yes

STUN

---

---

Yes

TG/COS

---

---

Yes

QLLC

---

---

Yes

Bisync

---

---

Yes

DSPU

---

---

Yes

NetView Native Service Point

---

---

Yes

Protocol translation

---

---

Yes

TN3270

---

---

Yes

LAT

---

---

Yes

SRT bridging

---

---

Yes

XRemote

---

---

Yes

Telnet

Yes

Yes

Yes

PAD

Yes

Yes

Yes

AutoInstall

Yes

Yes

Yes

Modem autoconfiguring

---

---

Yes

Router monitoring

Yes

Yes

Yes

DHCP

Yes

Yes

Yes

NASI

---

---

---

NetBEUI over PPP

---

---

Yes

RADIUS

Yes

Yes

Yes

Modem Management

Yes

Yes

Yes

1All feature sets include RMON alarm and events groups. Full, nine-group RMON support is included in the feature sets indicated.


Table 11: Cisco 4000 Series Software Feature Sets
Feature Feature Set
IP IP/IBM Base IP/IPX IP/IPX/
IBM Base 		IP/IPX/
IBM/
APPN 		Desktop Desktop/
IBM Base 		Enterprise Enterprise/APPN

SNMP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RMON (events and alarms)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Asynchronous support (SLIP)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

ARAP

---

---

---

---

---

---

---

---

---

Frame Relay

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

SMDS

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

X.25

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

ISDN

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PPP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

HDLC

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IGRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Enhanced IGRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

OSPF

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

BGP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

EGP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PIM

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NHRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

ES-IS

---

---

---

---

---

---

---

Yes

Yes

IS-IS

---

---

---

---

---

---

---

Yes

Yes

Snapshot routing

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NTP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Bridging (transparent and translational)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Multiring

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

LAN extension host

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

IPX

---

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NLSP

---

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RTMP

---

---

---

---

---

Yes

Yes

Yes

Yes

SMRP

---

---

---

---

---

Yes

Yes

Yes

Yes

SRTP

---

---

---

---

---

---

---

Yes

Yes

IPXWAN 2.0

---

---

Yes

Yes

Yes

Yes

Yes

Yes

Yes

AppleTalk Versions 1 and 2

---

---

---

---

---

Yes

Yes

Yes

Yes

AURP

---

---

---

---

---

Yes

Yes

Yes

Yes

DECnet IV

---

---

---

---

---

Yes

Yes

Yes

Yes

DECnet V

---

---

---

---

---

---

---

Yes

Yes

Apollo Domain

---

---

---

---

---

---

---

Yes

Yes

Banyan VINES

---

---

---

---

---

---

---

Yes

Yes

ISO CLNS

---

---

---

---

---

---

---

Yes

Yes

XNS

---

---

---

---

---

---

---

Yes

Yes

V.120

---

---

---

---

---

---

---

Yes

Yes

SRB

---

Yes

---

Yes

Yes

---

Yes

Yes

Yes

RSRB

---

Yes

---

Yes

Yes

---

Yes

Yes

Yes

APPN

---

---

---

---

Yes

---

---

---

Yes

FRAS BAN

---

Yes

---

Yes

Yes

---

Yes

Yes

Yes

DLSw (RFC 1795)

---

Yes

---

Yes

Yes

---

Yes

Yes

Yes

DLSw+

---

Yes

---

Yes

Yes

---

Yes

Yes

Yes

SDLC

---

Yes

---

Yes

Yes

---

Yes

Yes

Yes

SDLLC

---

Yes

---

Yes

Yes

---

Yes

Yes

Yes

STUN

---

Yes

---

Yes

Yes

---

Yes

Yes

Yes

TG/COS

---

---

---

---

---

---

---

Yes

Yes

QLLC

---

Yes

---

Yes

Yes

---

Yes

Yes

Yes

Bisync

---

Yes

---

Yes

Yes

---

Yes

Yes

Yes

DSPU

---

---

---

---

---

---

---

Yes

Yes

NetView Native Service Point

---

Yes

---

---

Yes

Yes

Yes

Protocol translation

---

---

---

---

---

---

---

Yes

Yes

TN3270

---

---

---

---

---

---

---

Yes

Yes

LAT

---

---

---

---

---

---

---

Yes

Yes

XRemote

---

---

---

---

---

---

---

Yes

Yes

Telnet

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

PAD

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

AutoInstall

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Modem auto configuration

---

---

---

---

---

---

---

Yes

Yes

Router monitoring

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

DHCP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

SRT Bridging

---

Yes

---

Yes

Yes

---

Yes

Yes

Yes

NetBEUI over PPP

---

---

---

---

---

---

---

Yes

Yes


Table 12: Cisco 3000 Series Software Feature Sets
Feature Feature Set
Enterprise

SNMP

Yes

RMON (events and alarms)

Yes

Asynchronous support (SLIP)

Yes

ARAP

Yes

Frame Relay

Yes

SMDS

Yes

X.25

Yes

ISDN

Yes

PPP

Yes

HDLC

Yes

IP

Yes

RIP

Yes

IGRP

Yes

Enhanced IGRP

Yes

OSPF

Yes

BGP

Yes

EGP

Yes

PIM

Yes

NHRP

Yes

ES-IS

Yes

IS-IS

Yes

Snapshot routing

Yes

NTP

Yes

Transparent bridging

Yes

Translational bridging

Yes

Multiring

Yes

LAN extension host

Yes

IPX

Yes

NLSP

Yes

IPXWAN 2.0

Yes

AppleTalk Versions 1 and 2

Yes

AURP

Yes

DECnet

Yes

Apollo Domain

Yes

Banyan VINES

Yes

ISO CLNS

Yes

XNS

Yes

V.120

Yes

SRB

Yes

RSRB

Yes

SRT Bridging

Yes

APPN

---

FRAS BAN

Yes

DLSw (RFC 1795)

Yes

DLSw+

Yes

SDLC

Yes

SDLLC

Yes

STUN

Yes

TG/COS

Yes

QLLC

Yes

Bisync

Yes

DSPU

Yes

AutoInstall

Yes

Telnet

Yes

Protocol translation

Yes

TN3270

Yes

LAT

Yes

XRemote

Yes

DHCP

Yes

Router monitoring

Yes

NetBEUI over PPP

Yes


Table 13: Cisco 1003 and Cisco 1004 ISDN Routers Software Feature Sets
Feature Feature Set
IP IP/AT IP/IPX IP/IPX/AT

SNMP

Yes

Yes

Yes

Yes

Asynchronous support (SLIP)

---

---

---

---

ARAP

---

---

---

---

Frame Relay

---

---

---

---

SMDS

---

---

---

---

X.25

---

---

---

---

ISDN

Yes

Yes

Yes

Yes

PPP

Yes

Yes

Yes

Yes

HDLC

Yes

Yes

Yes

Yes

IP

Yes

Yes

Yes

Yes

RIP

Yes

Yes

Yes

Yes

IGRP

Yes

Yes

Yes

Yes

Enhanced IGRP

Yes

Yes

Yes

Yes

OSPF

---

---

---

---

BGP

---

---

---

---

EGP

---

---

---

---

PIM

---

---

---

---

NHRP

---

---

---

---

ES-IS

---

---

---

---

IS-IS

---

---

---

---

Snapshot routing

Yes

Yes

Yes

Yes

NTP

---

---

---

---

Bridging (transparent)

Yes

Yes

Yes

Yes

Multiring

---

---

---

---

LAN extension host

---

---

---

---

IPX

---

---

Yes

Yes

NLSP

---

---

---

---

IPXWAN 2.0

---

---

Yes

Yes

AppleTalk Versions 1 and 2

---

Yes

---

Yes

AURP

---

---

---

---

DECnet IV

---

---

---

---

DECnet V

---

---

---

---

Apollo Domain

---

---

---

---

Banyan VINES

---

---

---

---

ISO CLNS

---

---

---

---

XNS

---

---

---

---

V.120

---

---

---

---

SRB

---

---

---

---

RSRB

---

---

---

---

DLSw (RFC 1795)

---

---

---

---

DLSw+

---

---

---

---

SDLC

---

---

---

---

SDLLC

---

---

---

---

STUN

---

---

---

---

TG/COS

---

---

---

---

QLLC

---

---

---

---

DSPU

---

---

---

---

Protocol translation

---

---

---

---

TN3270

---

---

---

---

LAT

---

---

---

---

XRemote

---

---

---

---

Telnet

Yes

Yes

Yes

Yes

AutoInstall

---

---

---

---

ClickStart

Yes

Yes

Yes

Yes

Router monitoring

Yes

Yes

Yes

Yes

DHCP

---

---

---

---

Lock-and-Key

---

---

---

---


Table 14: Cisco 1005 Router Software Feature Sets
Feature Feature Set
IP IP/AT IP/AT/
X25 		IP/IPX IP/IPX/
X25 		IP/IPX/
AT 		IP/IPX/
AT/X25 		IP/OSPF/
PIM 		IP/IPX/
Async 		IP/
Async

SNMP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Asynchronous support (SLIP)

---

---

---

---

---

---

---

---

Yes

Yes

ARAP

---

---

---

---

---

---

---

---

---

---

Frame Relay

Yes

Yes

---

Yes

---

Yes

---

Yes

---

---

SMDS

Yes

Yes

---

Yes

---

Yes

---

Yes

---

---

X.25

Yes

---

Yes

---

Yes

---

Yes

Yes

---

---

ISDN

---

---

---

---

---

---

---

---

---

---

PPP

Yes

Yes

---

Yes

---

Yes

---

Yes

Yes

Yes

HDLC

Yes

Yes

---

Yes

---

Yes

---

Yes

---

---

IP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

RIPv2

---

---

---

---

---

---

---

---

---

---

IGRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Enhanced IGRP

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

OSPF

---

---

---

---

---

---

---

Yes

---

---

BGP

---

---

---

---

---

---

---

---

---

---

EGP

---

---

---

---

---

---

---

---

---

---

PIM

---

---

---

---

---

---

---

Yes

---

---

NHRP

---

---

---

---

---

---

---

---

---

---

ES-IS

---

---

---

---

---

---

---

---

---

---

IS-IS

---

---

---

---

---

---

---

---

---

---

Snapshot routing

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

NTP

---

---

---

---

---

---

---

---

---

---

Bridging (transparent)

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

---

---

Multiring

---

---

---

---

---

---

---

---

---

---

LAN extension host

---

---

---

---

---

---

---

---

---

---

IPX

---

Yes

---

Yes

Yes

Yes

Yes

---

Yes

---

NLSP

---

---

---

---

---

---

---

---

---

---

IPXWAN 2.0

---

Yes

---

Yes

Yes

Yes

Yes

---

Yes

---

AppleTalk Versions 1 and 2

---

Yes

Yes

---

---

Yes

Yes

---

---

---

AURP

---

---

---

---

---

---

---

---

---

---

DECnet IV

---

---

---

---

---

---

---

---

---

---

DECnet V

---

---

---

---

---

---

---

---

---

---

Apollo Domain

---

---

---

---

---

---

---

---

---

---

Banyan VINES

---

---

---

---

---

---

---

---

---

---

ISO CLNS

---

---

---

---

---

---

---

---

---

---

XNS

---

---

---

---

---

---

---

---

---

---

Source-route bridging/
remote source-route bridging

---

---

---

---

---

---

---

---

---

---

DLSw (RFC 1795)

---

---

---

---

---

---

---

---

---

---

DLSw+

---

---

---

---

---

---

---

---

---

---

SDLC

---

---

---

---

---

---

---

---

---

---

SDLLC

---

---

---

---

---

---

---

---

---

---

STUN

---

---

---

---

---

---

---

---

---

---

TG/COS

---

---

---

---

---

---

---

---

---

---

QLLC

---

---

---

---

---

---

---

---

---

---

DSPU

---

---

---

---

---

---

---

---

---

---

Protocol translation

---

---

---

---

---

---

---

---

---

---

TN3270

---

---

---

---

---

---

---

---

---

---

LAT

---

---

---

---

---

---

---

---

---

---

XRemote

---

---

---

---

---

---

---

---

---

---

Telnet

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

AutoInstall

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

---

---

ClickStart

Yes

Yes

---

Yes

---

Yes

---

Yes

Yes

Yes

Router monitoring

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

DHCP

---

---

---

---

---

---

---

---

---

---

Lock-and-Key

---

---

---

---

---

---

---

---

---

---

Memory Requirements

Beginning with Cisco  IOS Release  10.3, some software image (feature set) sizes exceed 4  MB and, when compressed, exceed 2  MB. Also, some systems now require more than 1 MB of main system memory for data structure tables.

For Cisco routers to take advantage of the Release  11.1 features, you need to have the code or main system memory as listed in Table 15. If you do not, you must upgrade your memory. Some platforms have specific chip or architecture requirements that affect what can be upgraded and in what increments.

The memory requirements listed in Table 15 are minimum requirements. Your specific hardware configuration and the software features you chose to deploy could require you to have more memory.

Note For the Cisco  7000 and Cisco  7010 routers to recognize Flash memory cards, 11.0 boot ROMs (or later) are required.


Table 15: Release  11.1 Memory Requirements
Hardware Platform Minimum Required Code Memory Required Main Memory Release  11.1Runs  from
Cisco 1003 and Cisco  1004 ISDN Routers1

IP Set

2/4/8 MB optional Flash

4 MB RAM

RAM

IP/AT Set

2/4/8 MB optional Flash

4 MB RAM

RAM

IP/IPX Set

2/4/8 MB optional Flash

4 MB RAM

RAM

IP/IPX/AT Set

2/4/8 MB optional Flash

8 MB RAM

RAM

Cisco 1005 Router1

IP Set

2/4/8 MB optional Flash

4 MB RAM

RAM

IP/AT Set

2/4/8 MB optional Flash

4 MB RAM

RAM

IP/AT/X25 Set

2/4/8 MB optional Flash

4 MB RAM

RAM

IP/IPX Set

2/4/8 MB optional Flash

4 MB RAM

RAM

IP/IPX/AT/X25 Set

2/4/8 MB optional Flash

8 MB RAM

RAM

IP/IPX/AT Set

2/4/8 MB optional Flash

8 MB RAM

RAM

IP/IPX/X25 Set

2/4/8 MB optional Flash

4 MB RAM

RAM

IP/IPX/Async Set

2/4/8 MB optional Flash

4 MB RAM

RAM

IP/Async Set

2/4/8 MB optional Flash

4 MB RAM

RAM

Cisco 2500 Series

IP Set

4 MB Flash

2 MB RAM2

Flash

IP/RMON Set

4 MB Flash

4 MB RAM

Flash

IP/IBM Set

8 MB Flash

4 MB RAM

Flash

IP/IBM/RMON Set

8 MB Flash

4 MB RAM

Flash

IP/IPX Set

8 MB Flash

4 MB RAM

Flash

IP/IPX/RMON Set

8 MB Flash

4 MB RAM

Flash

IP/IPX/IBM Set

8 MB Flash

4 MB RAM

Flash

IP/IPX/IBM/RMON Set

8 MB Flash

4 MB RAM

Flash

IP/IPX/IBM/APPN Set

8 MB Flash

8 MB RAM

Flash

Desktop Set

8 MB Flash

4 MB RAM

Flash

Desktop/IBM Set

8 MB Flash

4 MB RAM

Flash

Enterprise Set

8 MB Flash

16 MB RAM

Flash

Enterprise/RMON Set

8 MB Flash

6 MB RAM

Flash

Enterprise/APPN Set

16 MB Flash

8 MB RAM

Flash

Cisco Frame Relay Access Device (CFRAD) Set

4 MB Flash

2 MB RAM2

Flash

Remote Access Server

4 MB Flash

4 MB RAM

Flash

ISDN Set

4 MB Flash

2 MB RAM

Flash

LAN FRAD Set

4 MB Flash

4 MB RAM

Flash

OSPF LANFRAD Set3

4 MB Flash

4 MB RAM

Flash

Cisco  AS51004

IP Set

4 MB Flash per card

6 MB RAM per card

Flash

IP/RMON Set

4 MB Flash

6 MB RAM

Flash

IP/IBM Base Set

8 MB Flash

6 MB RAM

Flash

IP/IBM/RMON Set

8 MB Flash

6 MB RAM

Flash

IP/IPX Set

8 MB Flash per card

6 MB RAM per card

Flash

IP/IPX/RMON Set

8 MB Flash

6 MB RAM

Flash

IP/IPX/IBM Base Set

8 MB Flash

6 MB RAM

Flash

IP/IPX/IBM/RMON Set

8 MB Flash

6 MB RAM

Flash

Desktop Set

8 MB Flash per card

6 MB RAM per card

Flash

Desktop/IBM Base Set

8 MB Flash

6 MB RAM

Flash

Enterprise Set

8 MB Flash per card

16 MB RAM per card

Flash

Enterprise/RMON Set

8 MB Flash

6 MB RAM

Flash

Remote Access Server

4 MB Flash per card

6 MB RAM per card

Flash

Cisco  AS5200

IP/Managed Modems Set

8 MB Flash

8 MB RAM

Flash

Desktop/Managed Modems Set

8 MB Flash

8 MB RAM

Flash

Enterprise/RMON/
Managed Modems Set

8 MB Flash

8 MB RAM

Flash

Cisco 3101,
Cisco 3102,
Cisco 3103

8 MB Flash

4 MB RAM

Flash

4 MB Flash

16 MB RAM

RAM

Cisco 3104,
Cisco 3204

8 MB Flash

4 MB RAM

Flash

4 MB Flash

8 MB RAM

RAM

Cisco 4000/4000-M

Cisco 4000

Cisco 4000-M

IP Set

4 MB Flash

16 MB RAM

8 MB RAM

RAM

IP/IBM Set

4 MB Flash

16 MB RAM

8 MB RAM

RAM

IP/IPX Set

4 MB Flash

16 MB RAM

8 MB RAM

RAM

IP/IPX/IBM Set

4 MB Flash

16 MB RAM

8 MB RAM

RAM

IP/IPX/IBM/APPN Set

4 MB Flash

16 MB RAM

16 MB RAM

RAM

Desktop Set

4 MB Flash

16 MB RAM

8 MB RAM

RAM

Desktop/IBM Set

4 MB Flash

16 MB RAM

8 MB RAM

RAM

Enterprise Set

4 MB Flash

16 MB RAM

16 MB RAM

RAM

Enterprise/APPN Set

4 MB Flash

16 MB RAM

16 MB RAM

RAM

Cisco 4500/4500-M

Cisco 4500

Cisco 4500-M

IP Set

4 MB Flash

8 MB RAM

8 MB RAM5

RAM

IP/IBM Set

4 MB Flash

32 MB RAM

16 MB RAM

RAM

IP/IPX Set

4 MB Flash

8 MB RAM

8 MB RAM5

RAM

IP/IPX/IBM Set

4 MB Flash

32 MB RAM

16 MB RAM

RAM

IP/IPX/IBM/APPN Set

4 MB Flash

32 MB RAM

16 MB RAM

RAM

Desktop Set

4 MB Flash

32 MB RAM

16 MB RAM

RAM

Desktop/IBM Set

4 MB Flash

32 MB RAM

16 MB RAM

RAM

Enterprise Set

4 MB Flash

32 MB RAM

16 MB RAM

RAM

Enterprise/APPN Set

8 MB Flash

32 MB RAM

16 MB RAM

RAM

Cisco 4700

IP Set

4 MB Flash

16 MB RAM

RAM

IP/IBM Set

4 MB Flash

16 MB RAM

RAM

IP/IPX Set

4 MB Flash

16 MB RAM

RAM

IP/IPX/IBM Set

4 MB Flash

16 MB RAM

RAM

IP/IPX/IBM/APPN Set

4 MB Flash

16 MB RAM

RAM

Desktop Set

4 MB Flash

16 MB RAM

RAM

Desktop/IBM Set

4 MB Flash

16 MB RAM

RAM

Enterprise Set

4 MB Flash

16 MB RAM

RAM

Enterprise/APPN Set

8 MB Flash

16 MB RAM

RAM

Cisco 70006, Cisco 7010

IP Set

8 MB Flash

16 MB RAM

RAM

IP/IPX/IBM Set

8 MB Flash

16 MB RAM

RAM

IP/IPX/IBM/APPN Set

8 MB Flash

16 MB RAM

RAM

Desktop/IBM Set

8 MB Flash

16 MB RAM

RAM

Enterprise Set

8/16 MB Flash memory card

16 MB RAM

RAM

Enterprise/APPN Set

8 MB Flash

16 MB RAM

RAM

IP/VIP Set

8 MB Flash

16 MB RAM

RAM

IP/IPX/IBM/VIP Set

8 MB Flash

16 MB RAM

RAM

IP/IPX/IBM/APPN/VIP Set

8 MB Flash

16 MB RAM

RAM

Desktop/IBM/VIP Set

8 MB Flash

16 MB RAM

RAM

Enterprise/VIP Set

8/16 MB Flash memory card

16 MB RAM

RAM

Enterprise/APPN/VIP Set

8 MB Flash

16 MB RAM

RAM

Source-Route Switch

4 MB Flash

16 MB RAM

RAM

Cisco 7200

Enterprise Set

8/16/20 MB Flash memory card

16 MB RAM

RAM

Enterprise/APPN Set

8/16/20 MB Flash memory card

24 MB RAM

RAM

Desktop/IBM Set

8/16/20 MB Flash memory card

16 MB RAM

RAM

Network Layer 3 Switching Set

8/16/20 MB Flash memory card

16 MB RAM

RAM

Cisco 7505, Cisco  7507, Cisco  7513, Cisco  7000 with RSP7000



Cisco 7513 only



All Others

IP Set

8 MB Flash

16 MB RAM

16 MB RAM

RAM

IP/IPX/IBM Set

8 MB Flash

16 MB RAM

16 MB RAM

RAM

IP/IPX/IBM/APPN Set

8 MB Flash

24 MB RAM

24 MB RAM

RAM

Desktop/IBM Set

8 MB Flash

16 MB RAM

16 MB RAM

RAM

Enterprise Set

8 MB Flash memory card

24 MB RAM

16 MB RAM

RAM

Enterprise/APPN Set

8 MB Flash memory card

32 MB RAM

24 MB RAM

RAM

IP/VIP Set

8 MB Flash

24 MB RAM7

24 MB RAM8

RAM

IP/IPX/IBM/VIP Set

8 MB Flash

24 MB RAM7

24 MB RAM8

RAM

IP/IPX/IBM/APPN/VIP Set

8 MB Flash

24 MB RAM7

24 MB RAM8

RAM

Desktop/IBM/VIP Set

8 MB Flash

24 MB RAM7

24 MB RAM8

RAM

Enterprise/VIP Set

8/16/20 MB Flash memory card

32 MB RAM7

24 MB RAM8

RAM

Enterprise/APPN/VIP Set

8/16/20 MB Flash memory card

32 MB RAM7

32 MB RAM

RAM

1If you need to upgrade the main memory for your Cisco  1003, Cisco  1004, or Cisco  1005 router, be sure to order the upgrade specific to your router.
2For Cisco  2509 through Cisco 2512 access servers, and the Cisco 2522 and Cisco 2523 routers, 4 MB DRAM is the minimum recommended.
3The OSPF LANFRAD feature set is available in Release  11.1(9) and later.
4Memory requirements listed are per card. Each AS5100 supports up to three cards, so that the maximum memory needed for any AS5100 is three times the listed number.
5The Cisco  4500 requires 16 MB DRAM when two NP-CT1 or two NP-CE1 Network Processor Modules are installed in the chassis.
6Except the Cisco  7000 with RSP7000. For a Cisco  7000 with an RSP7000 card, refer to the memory requirements for Cisco  75xx platforms.
7To use the HSA feature, 32 MB DRAM is the minimum recommended memory (per RSP).
8To use the HSA feature, 24 MB DRAM is the minimum recommended memory (per RSP).

New Features in Release  11.1(6) and Later 11.1 Releases

There are no new software features or platform support added in Release  11.1(6) or in any later Cisco  IOS 11.1 release. Release  11.1(5) was the last maintenance release to add new features or platform support.

New Features in Release  11.1(5)

This section describes the software enhancements that were added to Release  11.1(5).

Support for Second-Generation Channel Interface (CIP2)

The CIP2 is the follow-on product to the original CIP, and provides increases in performance, capacity, reliability, and serviceability.

The CIP2 includes the following improvements over the original CIP:

The CIP2 operates with the CxBus in the Cisco  7000 series routers with either of the following processor types:

The CIP2 operates with the CyBus in the Cisco 7500 series routers, which use the Route Switch Processor (RSP).

CIP microcode is required if you will be using the CIP2. See the "Important Notes" section for more information about CIP microcode.

Support for Cisco 7200 Series Platforms

The Cisco  7200 series is a series of multiprotocol routers that delivers the high-performance, high port density, and availability features typically associated with high-end systems. The Cisco  7200 series supports Cisco's Inter-Switch Link (ISL) Protocol for transporting virtual LANs (VLANs) across Fast Ethernet. VLANs enable the logical definition of bridge groups that can be overlaid on the physical network.

The Cisco  7206 router can be configured with up to 48 Ethernet ports, 24 Token Ring ports, 24 serial ports, 7 Fast Ethernet ports, and 6 FDDI ports.

Four feature sets are available in Cisco  IOS Release  11.1(5) to support the Cisco  7200 series:

Refer to Table 6 for a list of features included in each of these sets.

Support for the Cisco AS5200

The Cisco  AS5200 Universal Access Server provides mixed asynchronous and ISDN line service to accommodate both mobile users and telecommuters with one server. This line of access servers contains channel service units (CSUs), channel banks, communication servers, switches, routers, and 48 modems in one standalone chassis that accommodates up to 48 users dialing-in simultaneously.

The following feature sets are available for the Cisco  AS5200. Refer to Table 10 for a complete list of the features provided in these sets.

Cisco Web Browser Interface

A Web browser interface is available on any Cisco product running Cisco  IOS Release  11.1(5) software, or later. This Web interface allows you to log in to a router or access server and process Cisco  IOS software commands. It operates much like the command line interface (CLI) on a terminal. To process commands using the Web interface, click on the "Monitor the Router" link from the router's home page. All Cisco products running Cisco  IOS Release  11.0(10) or 11.1(5) software or later have a home page.

ClickStart Enhancements

ClickStart, which allows you to use a standard Web browser to configure and monitor a Cisco router, has been enhanced. You can now use it to configure a Cisco  1005 router that has one Ethernet and either one Frame Relay or one asynchronous serial interface. For additional information about ClickStart, see the "New Features in Release 11.1(2)" section.

DLSw+ Enhancements

In Release  11.1(5), DLSw+ can be used as a "virtual" data-link control for other SNA features in the Cisco  IOS software, including:

LNM over DLSw+ allows DLSw+ to be used in Token Ring networks that are managed by IBM's LNM software. Using this feature, LNM can be used to manage Token Ring LANs, control access units, and Token Ring attached devices over a DLSw+ network. All management functions continue to operate as they would in a source-route bridged network or an RSRB network.
DSPU over DLSw+ allows Cisco's DSPU feature to operate in conjunction with DLSw+ in the same router. DLSw+ can be used either upstream (toward the mainframe) or downstream (away from the mainframe) of DSPU. DSPU concentration consolidates the appearance of multiple physical units (PUs) into a single PU appearance to VTAM, minimizing memory and cycles in central site resources (VTAM, NCP, and routers) and speeding network startup.
SNA service point over DLSw+ allows Cisco's SNA service point feature to be used in conjunction with DLSw+ in the same router. Using this feature, SNA service point can be configured in remote routers, and DLSw+ can provide the path for the remote service point PU to communicate with NetView. This allows full management visibility of resources from a NetView 390 console, while concurrently offering the value-added features of DLSw+ in an SNA network.

Support for Fast Ethernet---100E NIM for Cisco  4500 and Cisco  4700

Support for the Fast Ethernet network interface module (NIM) is added in Release  11.1(5). The Cisco  4500 series (Cisco 4500, Cisco 4500-M, Cisco 4700, and Cisco 4700-M) routers support a Fast Ethernet network interface module (NIM) with a PCI bus interface to its DEC21140 controller chip. The Fast Ethernet NIM for Cisco 4500 and Cisco 4700 provides a single full-duplex, 100-Mbps Ethernet interface.

MIP Flow Control

Custom queuing and priority queuing are now available for the MultiChannel Interface Processor (MIP) in RSP systems (Cisco  7500 series and Cisco 7000 series with RSP7000).

NetFlow Switching

NetFlow Switching brings the benefits of connection-oriented switching to network layer devices. With NetFlow Switching, routers become network switches able to combine quality-of-service and security capabilities with high performance. Coupled with the large bandwidth capacity of Cisco's 7500 series, NetFlow Switching allows customers to provide many of the capabilities associated with ATM on their existing routed infrastructure.

NetFlow Switching operates at the network and transport layers so it can incorporate user and application oriented information to make switching decisions such as allowing access and providing specific quality of service. NetFlow Switching achieves high performance by operating on connection-like flows between source/destination IP addresses. Cisco LAN Switches such as the Catalyst 5000, will be able to take advantage of NetFlow Switching with the incorporation of support for multilayer switching and Cisco  IOS software.

Optimum Switching

Optimum Switching is quite similar to fast switching from a high level. The optimum switching cache is a separate cache using a more efficient data structure than the fast-switching cache to achieve better performance. In addition, the data caching at the processor is optimized to boost performance further. Optimum Switching requires the architecture of the Cisco 7500 series Route Switch Processor (RSP).

Support for the Packet OC-3 Interface

Support for the Packet OC-3 interface on the Packet over SONET Interface Processor (POSIP) is added in Release  11.1(5). The POSIP for Cisco 7500 series and Cisco RSP/7000 routers provides a single 155.520-Mbps, OC-3 physical layer interface for packet-based traffic. This OC-3 interface is fully compatible with SONET and Synchronous Digital Hierarchy (SDH) network facilities and is compliant with RFC 1619, "PPP over SONET/SDH," and RFC 1662, "PPP in HDLC-like Framing."

To support this interface, Packet over SONET Interface Processor microcode is also added to this release.

New Features in Release  11.1(4)

This section describes the software enhancements that were added to Release  11.1(4).

New Feature Sets for Cisco  1005

Cisco  IOS Release  11.1(4) supports two new Cisco  1005 feature sets:

Refer to Table 14 for a list of features included in each of these sets.

High System Availability (HSA)

HSA is an advanced software feature of the Cisco  7500 series architecture. HSA increases the availability and uptime of the Cisco  7507 and Cisco  7513 routers. This increase is accomplished through a master/slave relationship between two RSPs. If the slave RSP detects an error condition, it automatically takes control and reboots the system without user intervention. This automatic action minimizes network interruption and increases system availability.

Note HSA requires a ROM Monitor upgrade. See the "Important Notes" section for more information.

HSA can be used in the following situations:

HSA is only supported in feature set images that include a "v" in the name, such as the RSP subset image rsp-jv-mz.111-4.

See the "Important Notes" section for more information.

New Features in Release  11.1(3)

This section describes the software enhancements that were added to Release  11.1(3).

Channel Service Unit/Data Service Unit (CSU/DSU) Management Information Base (MIB)

This Cisco-proprietary MIB for integrated CSU/DSU is available in Release  11.1(3) and later. This MIB is available for use with the Cisco  2524 and Cisco  2525 products, and is for T1 and switched 56-kbps interfaces. It enables network managers to retrieve line statistics and CSU/DSU configuration data.

Support for the Cisco  2524 and Cisco  2525 Platforms

The Cisco 2524 and Cisco 2525 routers eliminate the need for a separate terminal adapter on an ISDN line, or separate channel service unit/data service units (CSU/DSUs) on synchronous serial WAN interfaces.

These platforms support a removable BRI or BRI with integrated NT1 interface, a LAN interface (either Ethernet or Token Ring), and two WAN interface slots.

New commands have been added to the Cisco  IOS software to support the Cisco  2524 and Cisco  2525.

The Cisco  2524 and Cisco  2525 support RFC 1406, Definitions of Managed Objects for the DS1 and E1 Interface Types.

Cisco  IOS Release  11.0(5) also supports the Cisco  2524 and Cisco  2525 routers.

Note The Cisco  2524 and Cisco  2525 require a minimum 11.0(5)-level boot ROM.

Support for the Cisco  2520, Cisco  2521, Cisco  2522, and Cisco  2523 Platforms

The Cisco  2520 through Cisco  2523 models merge router and communication server features to serve access and telecommuting requirements in a single platform. WAN aggregation, telecommuting, branch office, and IBM protocol applications are well-suited to these Cisco devices.

The interfaces available in each model are shown below.

Cisco  2520

1 Ethernet, 2 high-speed synchronous serial, 2  low-speed synchronous/asynchronous serial, 1  ISDN BRI

Cisco  2521

1 Token Ring, 2 high-speed synchronous serial, 2  low-speed synchronous/asynchronous serial, 1  ISDN BRI

Cisco  2522

1 Ethernet, 2 high-speed synchronous serial, 8  low-speed synchronous/asynchronous serial, 1  ISDN BRI

Cisco  2523

1 Token Ring, 2 high-speed synchronous serial, 8  low-speed synchronous/asynchronous serial, 1  ISDN BRI

The low-speed serial interfaces (maximum speed 115.2 kbps) are capable of supporting both synchronous and asynchronous protocols.

LAN Frame Relay Access Device (FRAD) Feature Set

The LAN FRAD feature set is supported on the Cisco  2501, Cisco  2502, Cisco  2520, Cisco  2521, Cisco  2522, and Cisco  2523 routers.

IP/Open Shortest Path First (OSPF)/Protocol Independent Multicast (PIM) Feature Set

This feature set for the Cisco  1005 router contains the functionality of the IP feature set, but includes support for OSPF and PIM.

New Features in Release  11.1(2)

This section describes the software enhancements that were added to Release  11.1(2).

New Configuration Tool---ClickStart

ClickStart allows you to use a standard Web browser, such as Netscape or Mosaic, to configure and monitor a Cisco router. You can use ClickStart to configure a Cisco  1003 or Cisco  1004 router that has one Ethernet and one ISDN Basic Rate Interface (BRI). You configure the router to dial your Internet service provider, and your Internet service provider supplies an ISDN connection to the Internet. You can also use ClickStart to monitor any Cisco router that is running Cisco  IOS Release  11.1(2), Release  11.0(6), or later.

If you have a Cisco  1003 or Cisco  1004 router, you can automatically use ClickStart to monitor your router.

If you have any other Cisco router, you must enable ClickStart before you can use it to monitor your router. To do this, follow this procedure:

Step 1 To enable ClickStart, use the ip http server global configuration command.

Step 2 By default, ClickStart uses port 80 to communicate with the router. If you want to configure a different port, use the ip http port number global configuration command. The number argument is the number of the port you want to use for ClickStart.

Virtual LAN (VLAN) Routing

Release  11.1(2) supports IP and IPX routing and transparent 802.1d bridging between Inter-Switch Link (ISL)-encapsulated VLANs on Cisco  7000 and Cisco  7500 series routers with RSPs. This functionality is also supported on the Cisco  7000 with Route Processors (RPs) and Switch Processors (SPs) and/or Silicon Switch Processors (SSPs), with limited performance.

VLAN allows you to logically segment end-user ports into autonomous virtual workgroups. Logical segmentation provides benefits in address administration, security, and management of network broadcast activity across the enterprise. To communicate between VLANs, a routing function is required (or bridging, in the case of nonroutable protocol types). Cisco  IOS software offers two alternatives for communication between VLANs: dedicated VLAN ports and VLAN subinterfaces.

Note that the only IPX encapsulation supported in ISL is 802.3.

Security access lists for controlling the type of access within or outside of a VLAN can be configured using subinterfaces within Cisco routers. This control provides an additional layer of security when VLANs are interconnected.

VLAN routing

New Features in Release  11.1(1)

This section describes new features and enhancements available in the initial Cisco  IOS Release  11.1 of the router products software.

Platform Support

This section describes new platforms and interfaces supported by the initial release of Cisco  IOS Release  11.1.

Cisco  1005

The Cisco 1005 synchronous serial router connects small, remote Ethernet LANs to WANs over leased lines, Frame Relay, Switched Multimegabit Data Service (SMDS), Switched-56, and X.25. The Cisco  1005 is already supported on Releases  11.0(4), 10.3(6), and higher.

AAL3/4 E3/DS3 for Cisco  4500 and Cisco  4700 ATM NIM

Asynchronous Transfer Mode (ATM) is supported on the Cisco  4500 and Cisco  4700 routers, using the Cisco ATM Network Interface Module (NIM) cards. The ATM adaptation layer 3/4 (AAL3/4), and additional NIM variants for use with E3/DS3 services are supported in Release  11.1. (Support is also available in Cisco  IOS Release  11.0(5).) ATM on the Cisco 4500 and Cisco 4700 routers is configured differently from that on the Cisco  7000 routers. Refer to the Wide-Area Networking Configuration Guide for configuration information.

Backbone Protocol Routing Features

This section describes the backbone protocol routing features that are new in the initial release of Cisco  IOS Release  11.1.

TCP/IP Features

The following features have been added to the Cisco  IOS TCP/IP software:

NHRP has been enhanced to support IPX in addition to the IP support introduced in Cisco  IOS Release  10.3. With NHRP, you can dynamically resolve IPX addresses in large-scale WAN environments in addition to resolving IP addresses. NHRP will operate using ATM, SMDS, or GRE tunneling.
Fast Install ensures that the floating static route is installed as soon as either the routing protocol or interface reports a connectivity loss. This enables faster convergence when using dial-on-demand circuits to back up, for example, a leased-line or Frame Relay service.
Note MD5 authentication in RIPv2 is not supported in Release  11.1(1) or Release  11.1(2).
If you implement RIP you can now make more efficient use of allocated address space by implementing variable-length subnet masks (VLSM) within networks.
RIPv2 adds to the choices of classless routing protocols supported by Cisco  IOS software. This is the primary mechanism to improve scaling of the Internet routing system as a whole.
Note Care must be taken when combining RIPv2 routers and RIPv1-compatible hosts. Because it cannot apply the supplied subnet mask, a RIPv1 host may misinterpret route information.
In some multi-homed environments, hosts listen to RIPv1 broadcasts to enable them to switch their traffic to a new router, should the main router or connection fail. Cisco recommends the choice of alternative technologies such as RFC 792 ICMP Router Discovery Protocol, or Hot Standby Router Protocol (HSRP) as alternatives for hosts.

Desktop Protocols

This section describes the desktop protocol features that are new in the initial release of Cisco  IOS Release  11.1.

AppleTalk Features

The following features have been added to Cisco's AppleTalk software:

SMRP optimizes Apple Computer's Quicktime Conferencing (QTC) traffic flow of audio, video, and shared data over AppleTalk-based routed networks. QTC is a powerful multimedia application that enables multiple end stations to participate in multipoint, collaborative, multimedia operations. SMRP is the networking complement of QTC. SMRP optimizes communication among QTC end systems with reduced CPU utilization by eliminating the duplicate transmission of identical packets to multiple receivers. SMRP streamlines network throughput by eliminating duplicate and unnecessary traffic propagation. It dynamically establishes unique shortest-path distribution trees to restrict traffic propagation to only those parts of the network that contain receiving end stations. SMRP provides just-in-time packet duplication upon encountering a branch in the distribution tree.
Cisco routers have been SMRP-enabled since Cisco  IOS Release  11.0. New in this release is enhanced performance through fast switching on the Cisco  4000 and Cisco  7500 series routers.

ISO CLNS Features

The benefits for TARP include:

Novell Features

The following features have been added to Cisco's Novell software:

Enhanced IGRP to NLSP route redistribution provides unparalleled flexibility to users of large IPX networks. Previously, when IPX networks grew to the point where RIP and SAP were no longer able to adequately support them, users were forced to upgrade to either Enhanced IGRP or NLSP to gain the scalability benefits inherent to these protocols. Through the use of Enhanced IGRP to NLSP route redistribution, users may now select the routing protocol, or combination of routing protocols, that meets their needs. For example, an IPX network can now be built that uses a combination of RIP and NLSP on the NetWare servers and uses Enhanced IGRP as the single backbone protocol.
Note IPX Input Access Lists can be fast switched, but they cannot be enabled on a cBus-based router configured for autonomous or SSE switching.
Other implementations of load sharing rely on a round-robin algorithm that transmits successive packets over alternate, equal-cost paths without regard to the end host. Round-robin load sharing increases the likelihood of packets being received out of order at the destination host. Out-of-order packets must often be retransmitted in IPX environments, leading to much higher application delay and network congestion.
Because per-host load sharing sends all packets destined for an end host over the same media interface, the likelihood of packets being received out of order is greatly reduced and minimizes retransmissions and network overhead.
NLSP route aggregation provides several important benefits to users of large IPX networks:
It is recommended that large IPX networks (conservatively estimated as those containing over 400 network addresses according to Novell design guidelines) be split into smaller NLSP areas. Previously, NLSP was specified as a single-area routing protocol, meaning that individual NLSP areas had to use IPX RIP to communicate routing information. Cisco's new implementation of NLSP allows multiple instances of NLSP to run on the same router, and allows routing information to be redistributed between areas. This allows much larger NLSP networks to exist.
When possible, ranges of addresses within an area can be aggregated (or summarized) into a single route entry. Because the number of these entries in the routing databases is minimized and update traffic is reduced, aggregation results in a much more efficient routing process.
Note To derive the maximum benefit from NLSP route aggregation it is important that network addresses be assigned properly in IPX environments. Network addresses should be assigned in a structured, hierarchical manner. Additionally, since other IPX routing protocols cannot interpret summarized route entries, the use of NLSP route aggregation in a Cisco router that is also using IPX RIP or Enhanced IGRP must be carefully planned and implemented.
Without routing support for FDDI_RAW IPX encapsulation, packets of this format are recognized only by switches or bridges on the FDDI ring. Neither clients, servers, nor routers directly connected to the ring can recognize this type of packet. By implementing FDDI_RAW encapsulation, it is possible to recognize and route these packets, either to other LAN or WAN media, or back onto FDDI in one of the Novell-approved FDDI formats. Routing support for FDDI_RAW can eliminate the requirement of changing Ethernet encapsulation on servers and clients when deploying switched internetworks.
IPX header compression can reduce header information size from 30 bytes to as little as 1 byte. This can save bandwidth and reduce costs associated with IPX routing over WAN links. In addition, the use of CIPX is negotiated automatically on WAN links using the IPXWAN protocol, which reduces the complexity of implementing these circuits.

Wide-Area Networking Features

This section describes the wide-area networking features that are new in the initial release of Cisco  IOS Release  11.1.

ISDN/DDR Enhancements

The following feature has been added to Cisco's ISDN and DDR software:

SMDS

The following features have been added to Cisco's SMDS software:

Only IEEE 802.3, IEEE 802.5, and FDDI with or without frame check sequence (FCS) frames will be supported in the fast-switched and process-switched modes. Previously, only IEEE 802.3 frames were process-switched.

ATM Enhancements

The following features have been added to Cisco's Asynchronous Transfer Mode (ATM) software:

Core Enhancements

The following features have been added to the Cisco 7000 series and Cisco 7500 series routers:

The VIP-1FE is based on a single one-port Fast Ethernet port adapter. The VIP-1FE/1FE is based on two one-port Fast Ethernet port adapters. Both the VIP-1FE and VIP-1FE/1FE support IEEE  802.3u Fast Ethernet specifications for half- and full-duplex operation.
The VIP-1FE/4E is based on a one-port Fast Ethernet port adapter that supports distributed IP switching for the FEIP and a four-port (10BaseT) Ethernet port adapter. VIP distributed IP switching can switch to these output interfaces: VIP-FE/4E, VIP-FE, EIP, FIP, and FSIP, HIP, and MIP with HDLC encapsulations. (VIP distributed IP switching is not available in Release  11.1(1). It will be available in a future maintenance release of Cisco  IOS Release  11.1.)
Each Fast Ethernet port has an RJ-45 connector (100BaseTX, two-pair category 5 UTP), and an MII connector that provides connectivity to 100BaseFX and 100BaseT4 through customer-provided external transceivers. The Fast Ethernet port adapters can be configured for Inter-Switch Link (ISL), which supports VLANs between Catalyst 5000 high-performance switches and IEEE 802.1000 TB-VLAN for transparently bridging VLANs. (ISL is not supported in Release  11.1(1), but will be supported in Release  11.1(2) for RSP and RSP7000 processors with the FEIP and VIP cards.)
Because of its modular design, the VIP can be configured to support mixed media. Because this version of the VIP supports both Ethernet and Fast Ethernet, customers can now realize much better slot utilization in either the Cisco  7000 series or the Cisco  7500 series.
For full-duplex operation, the VIP-1FE is recommended.
The primary goal of distributed IP switching is to provide scalable switching performance for the Cisco  7500 series of high-end multiprotocol routers. With the introduction of distributed IP switching, Cisco  7500 switching performance scales as more VIPs are introduced into the system. VIP distributed IP switching can switch to these output interfaces: VIP-FE/4E, VIP-FE, EIP, FIP, and FSIP, HIP, and MIP with HDLC encapsulations.
VIP Distributed Switching requires the architecture of the Cisco  7500 series Route Switch Processor (RSP). VIP distributed IP flow switching is not available for VIPs installed in Cisco  7000 series platforms.
HSA is an advanced software feature of the Cisco  7500 series architecture. HSA increases the availability and uptime of the Cisco  7507 and Cisco  7513 routers. This increase is accomplished through a master/slave relationship between two RSPs. If the slave RSP detects an error condition it automatically takes control and reboots the system without user intervention. This automatic action minimizes network interruption and increases system availability.
HSA can be used in the following situations:
This feature became available in Cisco  IOS Release  11.1(4).
Note HSA requires a ROM Monitor upgrade. See the "Important Notes" section for more information.
The SMIP is a 2-port channelized interface processor that supports T1 and E1 interfaces and offers the same port configuration options as the MIP.
In conjunction with the Cisco  1000 series, the SSIP and SMIP provide the capability to cost-effectively network even the smallest branches. For Internet service providers, the SSIP, SMIP, and Cisco  1000 series significantly reduce the cost of adding customers, which allows Internet services to be profitably provided to a larger market.
The SSIP and SMIP do not currently support full Cisco  IOS software functionality. Please refer to Product Bulletin 397, which details the Cisco  IOS software functionality supported by the SSIP and SMIP.
Although these features are included in Cisco  IOS Software Release  11.1, the SSIP and SMIP are already supported in Release  10.3(6), Release  11.0(4), and later.
Note Cisco routers do not support SRB over FDDI when the router is an end station on an FDDI LAN.
The Flash MIB enables a user to use network management stations and CiscoWorks to manage and upgrade router software. With MIB support, this feature is now SNMP-manageable.
RSP7000 functionality is similar to a Cisco  7505 with RSP1, except that CyBus is not supported. CIP, FEIP, and VIP (CyBus interface processors) operate in CxBus mode.

Access and Communication Servers

In Cisco  IOS Release  11.1, the network manager can have a trap message sent when the source MAC address violation occurs. The SNMP trap message may be sent once, or at a decaying rate. The decaying rate option provides the first SNMP trap message immediately, the second trap at 2 minutes, the third trap at 4 minutes. This continues until 32 minutes have passed. The decaying trap messages can be terminated by the NMS by using the MIB variable TrapAcked.
Additional MIB variables are provided in the agent to allow the NMS to query the violation. MAC security MIB variables provide information such as last illegal source address, timestamp of the first violation, timestamp of the last violation, and number of violation frames.
Because SNMP uses UDP, a single trap notification might get lost. It is possible to configure the router to send multiple traps at a decaying rate. This ensures that the trap message will be received by the NMS.
LANE is also the underlying technology that supports virtual LANs (VLANs) over ATM networks. By providing the needed Layer 3 routing connection between Layer 2 VLANs, a Cisco  4500 or Cisco  4700 router with an NP-1A ATM network processor module and LANE technology provides standards-based routing between VLANs over ATM.
LANE requires Interim Local Management Interface (ILMI) and point-to-multipoint signaling capabilities on the switches on which it operates (VP tunneling is acceptable where signaling is not offered, such as a ATM WAN). The LANE services on the router ATM interfaces interoperate with Cisco LECs, including Cisco's ATM NICs and the Catalyst 5000. Cisco is pursuing interoperability with other third-party ATM LECs.

IBM Functionality Features

This section describes the IBM network software features and support that are new in the initial release of Cisco  IOS Release  11.1.

New Features

The following new IBM software features are available:

This feature simplifies network management by providing additional visibility of SNA network resources and by sending notifications about problems with PU and LU connectivity. When a downstream PU changes state, a DSPU is unable to activate a downstream PU, or a DSPU is unable to activate a downstream LU, it is mapped to an SNA message sent to a host operator, which generally appears in a NetView or NetMaster log. To minimize unnecessary noise across the network and in SNMP and NetView or NetMaster logs, there are four configurable notification levels (off, low, medium, and high).
Data link layer enhancements include:
APPN over PPP also allows APPN to be transported over an Integrated Switched Digital Network (ISDN).
Enhanced logging and debugging functions enable debug output that is more meaningful and useful, including better documentation of the error and debug output, more user control of the type and amount of debug output generated, and more descriptive information in the messages.
Because there is no standard way for transporting APPN over SMDS, a Cisco-proprietary method is used.
Note In some cases, APPN over SMDS may not interoperate with other vendors' SMDS implementations, because a proprietary method is being implemented.
BAN simplifies configuration in an environment where multiple remote SNA devices need to share a single PVC, and where there are no central site routers for SNA. It offers load balancing and provides the flexibility to build a redundant path to the Network Control Programs (NCPs).
Note BAN only applies to SNA devices on Ethernet or Token Ring. It does not apply to SDLC-attached devices. BAN requires NCP 7.3 at the central site. BNN and BAN can share the same DLCI to the NCP.

Data Link Switching+ (DLSw+) Features and Enhancements

The following features have been added to Cisco's DLSw+ software:

LNM support includes configuration report services, ring error monitor, and the ring parameter server. In addition, the DLSw+ router notifies LNM of certain events that might occur on a Token Ring, such as notification of a new station joining the Token Ring, or that the ring has entered failure mode known as beaconing.
This feature will be available in a future Cisco  IOS 11.1 software maintenance release.
These enhancements minimize WAN costs in switched environments. In addition, peer connections are only established when needed, maximizing scalability and minimizing cost.

Access and Communication Server Features

This section describes the access and communication server features that are new in the initial release of Cisco  IOS Release  11.1.

NBFCP:
With NBFCP:
With modem auto-configuring, no direct configuration of modems is required. All modems with a modem database entry are automatically recognized, and modems not found in the modem database can be defined clearly and quickly as the access server prompts for specific modem command strings.
Using the NCS server network, network managers can offer IPX dial-in and dial-out services on the same Cisco access server.
Note Because of Novell split-horizon rules it is necessary to disable all other NCS servers on the same network where the Cisco access server is deployed for NASI outbound connections.
This feature allows the identification of a username associated with a TCP connection.
The Identification Protocol support is not useful for securing access servers. It is a protocol for identifying the other end of a TCP connection. It does not authenticate or authorize the connection.
Cisco is implementing a two-phased approach to the implementation of Kerberos. Phase 1, delivered in Cisco  IOS Release  11.1, permits authentication on the router using Kerberos. (Phase 2, which will be available in another major Cisco  IOS software release, will allow a user to carry credentials to other services, such as Telnet, without having to reauthenticate.)
A Cisco white paper explaining Kerberos in more detail can be found on the World Wide Web (you need to be a registered CCO user) at:
http://www.cisco.com/warp/public/789/1.html
The server resides on a central computer typically at the user's site. The clients reside in the dial-up access servers and can be distributed throughout the network. The RADIUS client is available in Cisco  IOS Release  11.1.
Cisco's implementation of RADIUS is currently defined in draft documents at ftp.livingston.com:pub/radius/draft-ietf-radius-radius-02.txt. Cisco's implementation is based on this version of the draft. Cisco will attempt to keep current with any newer drafts issued. A sample RADIUS server can be obtained from Livingston's FTP site.
RADIUS is configured on the network access server much like TACACS+.

Network Management Features

This section describes the network management feature that is new in the initial release of Cisco  IOS Release  11.1.

Note As a security precaution, the packet capture group captures only useful packet header information; data payloads are not captured.
All Cisco  IOS software images that do not explicitly include full RMON support include RMON alarm and events groups. These groups can be coupled with existing Cisco MIB variables and allow customers to set thresholds and alarms on any MIB variables supported by Cisco.
RMON not only provides visibility of individual nodal activity, it allows the monitoring of all nodes and their interaction on a LAN segment. RMON used specifically as an agent in the router allows network managers to view either only traffic that flows through the router or all Ethernet segment traffic not necessarily destined for the router.
An RMON console application such as Cisco Traffic Director or NETscout Manager by Frontier Software Development, Inc., is required to take full advantage of the embedded RMON's network management capabilities.

Security Features

This section describes the security feature that is new in the initial release of Cisco  IOS Release  11.1.

Before Lock-and-Key access, IP access lists were created and maintained by manually defining lists on a router and distributing them to all other routers in the network. In networks with many hosts, this task could consume time and resources. Access lists do not provide any challenge mechanism beyond a static network address, making it possible for an unauthorized user to access network resources through any authorized network address. The Lock-and-Key access feature is an ideal solution for the proliferation of remote networks. Lock-and-Key access supports various WAN technologies such as ISDN, Frame Relay, X.25, dial-on-demand routing (DDR), and Point-to-Point Protocol (PPP).
When a user Telnets to a router configured with Lock-and-Key access, the software challenges the user to respond to a login and password prompt before placing a temporary entry in the dynamic access list. The network administrator can dictate an idle time-out or an absolute period for authorization and reauthorization.
Lock-and-Key access provides the following benefits:
Lock-and-Key access requires Telnet. Standard Telnet is the required application on the host platform that activates a Lock-and-Key session.
Further information on Lock-and-Key access can be found on the World Wide Web in the Cisco  IOS Lock and Key white paper (Product Bulletin 308) at http://www.cisco.com/warp/customer/417/66.html. (You need to be a registered CCO user.)

Important Notes

This section describes warnings and cautions about using the Cisco  IOS Release  11.1 software. This section discusses these topics:

BSC and SDLC Commands in Release  11.1(2)

In Release  11.1(2), the bsc fdx and sdlc hdx commands were deprecated and replaced by the full-duplex and half-duplex commands, respectively. The deprecated commands continue to be supported in Release  11.1(2) and later, but might not be supported in the next major release of Cisco  IOS software.

Upgrading to a New Software Release

If you are upgrading to Cisco  IOS Release  11.1 from an earlier Cisco  IOS software release, you should save your current configuration file before installing Release  11.1 software on your router.

Channel Interface Processor (CIP) Microcode

Starting with Cisco  IOS Release  11.1, CIP microcode is available as a separate image, unbundled from the Cisco  IOS image. CIP microcode (for the CIP or second-generation (CIP2)) resides only in router Flash memory as multiple files. The router loads a "kernel" to the CIP (based on hardware revision), and the CIP selectively loads and relocates the software it requires from the router's Flash memory. The CIP image is available on pre-loaded Flash memory cards, on floppy diskette, or via FTP from Cisco. Every version of Cisco  IOS Release  11.1 has a corresponding version of CIP microcode. Refer to the Channel Interface Processor (CIP) Microcode Release Note and Microcode Upgrade Requirements publication (Document Number 78-4715 -xx) for information about the recommended pairs of Cisco  IOS Release  11.1 and CIP microcode.

The CIP loader has the following effect on the router's system memory requirements:

Consider the following before you use the CIP loader:

When the CIP image is copied to an existing Flash memory card, the existing flash copy commands are used, just as before. If a CIP image other than the default for the release is being used, then the microcode cip flash configuration command must be issued.

The show microcode command has been expanded to display the default CIP image name for the Cisco  IOS release.

Note The router must already be running Cisco  IOS Release  11.1 before performing a copy of the CIP image to Flash memory, because the CIP image must be "exploded" from the single image file on the TFTP server to multiple files in Flash memory. This capability is added in Release  11.1.

There are a number of ways to determine what is loaded on each CIP:

Multiple CIP cards of different hardware revisions can run in the same router.

Cisco 7500 Series High System Availability (HSA)

To successfully use the HSA feature, you should take note of the following:

%RSP-3-INVRSP_IPC: Slave RSP slot x not supported with VIP slot y, crashing router
[CSCdi60891]

VLAN Routing

Support for VLAN routing is not available in Release  11.1(1). Support for this feature is available in Release  11.1(2). VLAN routing allows Inter-Switch Link (ISL)-encapsulated IP, IPX, and transparently bridged traffic to be routed or bridged to any other VLAN or native interface.

Netbooting from VIP

To netboot from Ethernet or Fast Ethernet ports on a VIP card the system must contain version 11.1 boot ROMs. If the system contains version 11.0 boot ROMs, you can work around this requirement by using the boot bootldr device: filename global configuration command to load a bootstrap image from Flash memory.

Source-Route Bridging (SRB) over FDDI

This feature supports forwarding of source-route bridged traffic between Token Ring and FDDI interfaces on the Cisco  7000, Cisco  7010, and Cisco  7500 series routers. Previously, the only way to transport SNA and NetBIOS over FDDI was with remote source-route bridging (RSRB), which is either fast switched (direct or Fast-Sequence Transport (FST) encapsulation) or process-switched (TCP encapsulation). With SRB over FDDI, traffic can be autonomously switched, greatly improving performance for SRB traffic that uses FDDI as a backbone. This feature eliminates the need for RSRB peer definitions to connect Token Ring networks over the FDDI backbone.

Note SRB over FDDI does not support RSRB traffic forwarded to RSRB peers. Routers that have connections to local Token Ring networks as well as RSRB connections to remote networks cannot use this feature. The work around is to move the RSRB connections to routers that are not connected to the FDDI backbone.

Enabling IPX Routing

The Token Ring interface is reset whenever IPX routing is enabled on that interface.

Using AIP Cards

Cisco  7000 series ATM Interface Processor (AIP) cards that support E3, DS3, or Transport Asynchronous Transmitter/Receiver Interface (TAXI) connections and that were shipped after February 22, 1995, require Cisco  IOS Release  10.0(9), 10.2(5), 10.3(1), or later.

Booting Cisco  4000 Routers

You must use the Release  9.14 rxboot image for Cisco  4000 routers because the Release  11.0 rxboot image is too large to fit in the ROMs. (Note that rxboot image size is not a problem for Cisco  4500 routers.) However, because the Release  9.14 rxboot image does not recognize new network processor modules, such as the Multiport Basic Rate Interface (MBRI), its use causes two problems:

Bad interface specification
No interface specified - IP address
Bad interface specification
No interface specified - IP address

Using LAN Emulation (LANE)

Note the following information regarding the LAN Emulation (LANE) feature:

Forwarding of Locally Sourced AppleTalk Packets

Our implementation of AppleTalk does not forward packets with local-source and destination network addresses. This behavior does not conform to the definition of AppleTalk in Apple Computer's Inside AppleTalk publication. However, this behavior is designed to prevent any possible corruption of the AppleTalk Address Resolution Protocol (AARP) table in any AppleTalk node that is performing MAC-address gleaning.

Using Source-Route Transparent Bridging (SRT) and Source-Route Bridging (SRB) on Cisco  2500 and Cisco  4000 Routers

Certain products containing the Texas Instruments TMS380C26 Token Ring controller do not support SRT. SRT is the concurrent operation of SRB and transparent bridging on the same interface. The affected products, shipped between March  30, 1994, and January 16, 1995, are the Cisco  4000 NP-1R, Cisco  4000 NP-2R, Cisco  2502, Cisco  2504, Cisco  2510, Cisco  2512, Cisco  2513, and Cisco  2515.

Units shipped before March 30, 1994, or after January 16, 1995 are not affected. They use the Texas Instruments TMS380C16 Token Ring controller, which supports SRT.

SRT support is necessary in two situations. In one, Token Ring networks are configured to SRB protocols such as SNA and NetBIOS, and they transparently bridge other protocols, such as IPX. In the other situation, SNA or NetBIOS uses SRB and Windows NT is configured to use NetBIOS over IP. Certain other configuration alternatives do not require SRT (contact the Technical Assistance Center for more information).

As of Release  10.3(1), SRB in the following Cisco  IOS features sets is no longer supported: IP, IP/IPX, and Desktop. To use SRB, you need one of the following feature sets: IP/IBM base, IP/IPX/IBM base, IP/IPX/IBM/APPN, Desktop/IBM base, Enterprise, or Enterprise/APPN. In most non-IBM Token Ring environments, the multiring feature in IP, IP/IPX, and Desktop eliminates the need for IP/IBM base, IP/IPX/IBM base, IP/IPX/IBM/APPN, Desktop/IBM base, Enterprise, or Enterprise/APPN.

Release  11.1(5a)

After the release of Cisco  IOS Release  11.1(5), a caveat was discovered within the Cisco  IOS rsp- images. It was determined that this caveat was significant enough to merit a rebuild of the rsp- images. The rebuild includes the caveat fix and is renumbered to 11.1(5a).

This defect is bug CSCdi66673 and is described as follows:

When Ethernet runt packets are received by Cisco 7500 series router processors (RSP1, RSP2, or RSP7000), a Reserved Exception crash or a QAERROR error will occur. When either of these problems happens, a switching complex restart is forced. The Reserved Exception crash has the following output:

Queued messages:
Aug 14 10:44:16: %RSP-3-ERROR: memd write exception, addr 08000000
Aug 14 10:44:16: %RSP-3-ERROR:   RSP alignment error on write to QA, addr 080000
00
*** System received a reserved exception ***
signal= 0x9, code= 0x0, context= 0x60c72fd0
PC = 0x60107514, Cause = 0x2020, Status Reg = 0x34008702
DCL Masked Interrupt Register = 0x000000ff
DCL Interrupt Value Register = 0x00000000
MEMD Int 6 Status Register = 0x00000000

The QAERROR error has the following output:

Jun 17 10:50:23.329: %RSP-2-QAERROR: reused or zero link error, write at addr 03
08 (QA)
  log 260308C0, data A816FFFF 00000000

Release  11.1(5a) and all subsequent releases of Cisco  IOS software, including Release  11.1(6), include the fix for this caveat.

Release  11.1(11a)

After the release of Cisco  IOS Release  11.1(11), caveats were discovered within the Cisco  IOS rsp- images. It was determined that these caveats were significant enough to merit a rebuild of the rsp- images. The rebuild includes the caveat fixes and is renumbered to 11.1(11a).

The defects are bugs CSCdi67315, CSCdj08722 and CSCdj09576 and are described as follows:

Release  11.1(11a) and all subsequent releases of Cisco  IOS software, including Release  11.1(12), include the fix for these caveats.

ATM Multipoint Signaling

Prior to Cisco IOS Release 11.1(13) and 11.2(8), the atm multipoint-signaling command was used on the main interface and affected all subinterfaces. For Release 11.1(13), 11.2(8) and later releases, explicit configuration on each subinterface is required to obtain the same functionality. Refer to bug CSCdj20944, which is described as follows:

Clients on different subinterfaces can have different behavior. Specifically 1577 requires point-to-point, and PIM allows point-to-multipoint. The command should be on a per subinterface basis.
Users will have to enable the atm multipoint-signaling command on all subinterfaces that require it. Previously, they only needed to enable it on the main interface.

Release  11.1(13a)

After the release of Cisco  IOS Release  11.1(13), caveats were discovered within the Cisco  IOS software. It was determined that these caveats were significant enough to merit a software rebuild. The rebuild includes the caveat fixes and is renumbered to 11.1(13a).

The defect is bug CSCdi73194. Related bugs are CSCdj25806, CSCdj25905, CSCdj26494, CSCdj26898, CSCdj28362, CSCdj30980, and CSCdj32710. CSCdi73194 is described as follows:

Release  11.1(13a) and all subsequent releases of Cisco  IOS software, including Release  11.1(14), include the fix for these caveats.

Caveats for Release 11.1(1) through 11.1(24)

This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(24). These caveats also apply to Releases 11.1(1) through 11.1(23) (unless otherwise noted).

Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.

Basic System Services

The only known workaround is to unconfigure the old interface processor before replacing it with the new one. Sometimes, it might even be necessary to issue a write erase command, reboot the router, and then redefine the existing interfaces to completely remove all configuration traces of the old interface processor. Once the information that is displayed by the show commands is self-consistent, the newly inserted interface processor behaves normally. [CSCdi49800]

DECnet

EXEC and Configuration Parser

System was restarted by bus error at PC 0x3122B6A, address 0xD0D0D3D
Stack trace may look similar to this:
Enter hex value: 0x312227A
0x312227A:_connect_new_session(0x30391f0+0xe9008)+0x82
Enter hex value: 0x31223EA
0x31223EA:_connect_command(0x30391f0+0xe90be)+0x13c
Enter hex value: 0x314C6D8
0x314C6D8:_parse_cmd(0x30391f0+0x113044)+0x4a4
Enter hex value: 0x3164850
0x3164850:_exec(0x30391f0+0x12b1e4)+0x47c
Enter hex value: 0x3144D38
0x3144D38:_process_hari_kari(0x30391f0+0x10bb48)+0x0
[CSCdj92253]

Interfaces and Bridging

IP Routing Protocols

ISO CLNS

Miscellaneous

Wide-Area Networking

atm_parse_packet(ATM4/0):Invalid VC(0) received, type=AAAA
Use the microcode reload command as a workaround to return the AIP to a normal state. [CSCdi77244]
LIF_Fatal called from CCPRI 0x600B578C, func =3D CCPRI_Mail, string Couldn't send a package to the HOST: 6
ExecExit called from 0x6008BC0C
%SYS-6-STACKLOW: Stack for process ISDN running low, 0/6000(GDB)
Stack contains : process_run_degraded_or_crash
The problem seems to be caused by overburdened ISDN lines. There is currently no workaround available. [CSCdj73619]
%SCHED-3-PAGEZERO: Low memory modified by Net Background (0x40 = 0x4AFC4AFB). -Traceback= 3128CD6 30D957C.
The workaround is to use the terminal window. [CSCdk25156]

Caveats for Release 11.1(1) through 11.1(23)

This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(23). Since Release 11.1 changed from a seven-week to a fourteen-week maintenance schedule after Release 11.1(18), Release  11.1(23) was only released as an interim version. These caveats also apply to Releases 11.1(1) through 11.1(22) (unless otherwise noted).

For more caveats of Release  11.1(23) and earlier 11.1 releases, see the preceding section, "Caveats for Release 11.1(1) through 11.1(24)."

Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.

All the caveats listed in this section are resolved in Release  11.1(24).

Basic System Services

IBM Connectivity

Interfaces and Bridging

Miscellaneous

Since PVC is always active in Cisco IOS Release 11.1, it should not have this problem. OSPF hello will always be sent down the PVC without being rejected. Once the memory leak has started it can be stopped by unconfiguring the IP OS network broadcast on the interface or making the interface become passive. [CSCdk62702]

Wide-Area Networking

Caveats for Release 11.1(1) through 11.1(22)

This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(22). These caveats also apply to Releases 11.1(1) through 11.1(22) (unless otherwise noted).

For more caveats of Release  11.1(22) and earlier 11.1 releases, see the preceding caveat sections.

Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.

All the caveats listed in this section are resolved in Release  11.1(23).

Basic System Services

Interfaces and Bridging

IP Routing Protocols

Miscellaneous

Wide-Area Networking

Caveats for Release 11.1(1) through 11.1(21)

This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(21). Since Release 11.1 changed from a seven-week to a fourteen-week maintenance schedule after Release 11.1(18), Release  11.1(21) was only released as an interim version. These caveats also apply to Releases 11.1(1) through 11.1(20) (unless otherwise noted).

For more caveats of Release  11.1(21) and earlier 11.1 releases, see the preceding section, "Caveats for Release 11.1(1) through 11.1(22)."

Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.

All the caveats listed in this section are resolved in Release  11.1(22).

IBM Connectivity

Interfaces and Bridging

IP Routing Protocols

The Enhanced IGRP event log is invalid on all platforms.
The workaround to this problem is not to display the event log or enable Enhanced IGRP event-logging. Additionally, the event log can be disabled by issuing one of the following configuration commands:
For IP: router eigrp as eigrp event-log-size 0
For IPX: ipx router eigrp as event-log-size 0
For AppleTalk: appletalk eigrp event-log-size 0 [CSCdk33475]

Wide-Area Networking

Caveats for Release 11.1(1) through 11.1(20)

This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(20). These caveats also apply to Releases 11.1(1) through 11.1(19) (unless otherwise noted).

For more caveats of Release  11.1(20) and earlier 11.1 releases, see all the preceding caveat sections.

Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.

All the caveats listed in this section are resolved in Release  11.1(21).

Basic System Services

A workaround for this problem is to make the "boot buffersize" in the config larger.We suggest 100K bytes larger than the configuration to allow room for configuration changes. [CSCdk14608]
This issue is due to corrupted SSP microcode which got incorporated into the release. The solution is to load a newer image which has uncorrupt SSP microcode or to load the uncorrupt SSP microcode directly. The Cisco IOS 11.1(20) release image contains the correct microcode. [CSCdk14917]

Interfaces and Bridging

IP Routing Protocols

ISO CLNS

TCP/IP Host-Mode Services

Wide-Area Networking

%SYS-2-INPUTQ: INPUTQ set, but no idb, ptr=60C43314
-Traceback= 60037A78 60039F6C 6003EF98


[CSCdi87914]





 Caveats for Release 11.1(1) through 11.1(19)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(19). Since Release 11.1 changed from a seven-week to a fourteen-week maintenance schedule after Release 11.1(18), Release  11.1(19) was only released as an interim version. These caveats also apply to Releases 11.1(1) through 11.1(18) (unless otherwise noted).


 For more caveats of Release  11.1(18) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(20).


 IBM Connectivity



 Interfaces and Bridging



 IP Routing Protocols



The loss of the route is due to sporadic line congestion (packet drops) and/or an SIA event on the same link as the neighbor occurring while a route is active. On very rare occasions, this can result in a lost acknowledge packet and a retransmission of the reply packet. For the failure to occur the retransmitted reply must have a valid metric.


A workaround is to issue the command clear ip route *. [CSCdj73617]





 ISO CLNS



Specifically, this can happen when the external route is known via the backup path, then becomes known via multiple optimal paths at about the same time, followed later by the loss of the optimal paths. The problem disappears when an SPF is run for any reason.


A workaround is to force an immediate SPF on the router (for example, by issuing the commands shutdown, no  shutdown on a loopback interface running ISIS). Note that this can be done on any router in the same area. [CSCdk05616]




 Miscellaneous



 Novell IPX, XNS, and Apollo Domain



A workaround is to run with fast switching disabled or clear the IPX route cache when this is noticed. [CSCdj59732]




 Wide-Area Networking



When running an image that has CSCdj93505 integrated into it, crash output for VIP2 products with a signal value of 20 indicates that a cache parity error condition was detected.


%VIP2 R5K-1-MSG: slot3 System Reload called from 0x..., context=0x...
%VIP2 R5K-1-MSG: slot3 System exception: sig=20, code=0x..., context=0x...


When this signal is present, the contents of the VIP crashinfo file are required for proper analysis.


When running an image that does not have CSCdj93505 integrated into it, the parity error may manifest in different ways. CSCdj20187 documents one such example. [CSCdj93505]





 Caveats for Release 11.1(1) through 11.1(18)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(18). These caveats also apply to Releases 11.1(1) through 11.1(17) (unless otherwise noted).


 For more caveats of Release  11.1(18) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(19).


 Basic System Services



%SYS-3-SUPNONE: Registry 23 doesn't exist


[CSCdj19276]





If this problem occurs, the configuration NVRAM of both the master and slave RSP will be invalid after a reboot and must be recovered manually as follows:


1. Send an RS-232 break to the console of both the master and slave.


2. Issue the ROM monitor confreg command on the master and slave to ignore the system configuration.


3. Issue the ROM monitor reset command on the master and slave to boot a slave-capable image.


4. On the master console, copy a good configuration file from Flash memory or TFTP into running-config.


5. Turn off the 0x40 bit in the configuration register by issuing the show version EXEC command and the config-register configuration command.


6. Issue the reload command to reload the master.


A workaround is to store the configuration in Flash memory. For example, issue the copy running slot0:config or write memory commands while configured with boot config slot0:config, service compress, and boot buffersize n, where n is at least three times the configuration size in bytes. In this case, the write memory command will work slowly - 10 minutes elapsed time for each 128k block of configuration text. [CSCdj63926]





It is also possible for this problem to occur on HDLC serial lines and cause instability due to HDLC keepalive packets being delayed.


This is a rare occurrence and has only been seen with very large IPX SAP updates sent over a slow-speed circuit. The size of updates necessary to cause this problem on a 56 kbps circuit is around 3000 SAPs. The problem is more likely to occur when there is data traffic at near-line capacity on the circuit.


It is theoretically possible for other routing or control packets such as OSPF Link State Advertisements (LSAs) or NLSP Link State Packets (LSPs) to cause the same effect in a period of severe routing instability in a large network with many Frame Relay subinterfaces. The issue is less likely to be seen when Weighted Fair Queuing is used on the serial interface rather than First In First Out (FIFO) queuing. Please note that there are many other possible causes of instability of Frame Relay or serial circuits and the manifestation of this particular caveat in operating networks is unlikely.


If the issue is seen because of very large IPX SAP updates, the workaround is to configure an ipx output-sap-delay and ipx output-rip-delay that is larger than the propagation delay of a SAP packet across the circuit. A delay of 110 ms is sufficient for a 56K circuit. The possibility of seeing this caveat with very large IPX SAP updates was introduced by CSCdj18092. [CSCdj91667]




 IBM Connectivity



There is currently no known workaround [CSCdj77914]





A workaround for this is to disable LNM on the router by issuing the command lnm disable. [CSCdj82340]





%APPN-7-APPNETERROR: Insufficient available buffer supply
%ALIGN-3-SPURIOUS: Spurious memory access made at 0x606F5A4C reading 0x50


The show stack command displays the following backtrace:


#0 0x606F5A4C in recreate_small_fid2_mu
#1 0x606fdbd4 in transfer_to_dynamic_and_send
#2 0x606fce90 in sc_process_mu
#3 0x606f6900 in e
#4 0x606f6ed8 in fsm_receive_router
#5 0x606d6b20 in upchuck
#6 0x606d6664 in rcv_cls_msg
#7 0x606d6208 in dlcdx_process_messages
#8 0x606f5e18 in xxxpcasm


[CSCdj92488]





 Interfaces and Bridging



     +-----------+
     |           |                              +---------+           +----+
     |Campus FDDI+------7000 P01----------------| 360     |           |392 |
     |           |      ring group xx x         |0x168    |           |x188|
     |           |      0x501                   |Token    |           |    |
     |Ring 2730  |                              |Ring     +----ACC----+    |
     |0xAAA      |                              |         |   Bridge  |    |
     |           +----- 7000 P02----------------|         |           |    |
     |           |      ring Group 1490         +---------+           +----+
     +-----------+     0x5D2
          |
          |
          |
         To Fep


 [CSCdj64489]





 IP Routing Protocols



The loss of the route is due to sporadic line congestion (packet drops) and/or an SIA event on the same link as the neighbor occurring while a route is active. On very rare occasions, this can result in a lost acknowledge packet and a retransmission of the reply packet. For the failure to occur the retransmitted reply must have a valid metric.


A workaround is to issue the command clear ip route *. [CSCdj73617]





Workaround is to set some of the interfaces passive and not change them to active. [CSCdj81611]





 Novell IPX, XNS, and Apollo Domain



A workaround is to run with fastswitching disabled or clear the IPX route cache when this is noticed. [CSCdj59732]




 Wide-Area Networking



It may be possible to work around the problem by using the mtu command to select a smaller MTU/MRU value for the interface, but this will only work if the remote peer agrees to negotiate the smaller value. Another workaround is to downgrade to a version of software that does not contain the CSCdi92482 patch.


To verify the problem, issue the debug ppp error command and search for a debug message of the following form:


Se6/0/0:23 PPP: Packet too large, size = 1509, maxsize = 4, protocol = 0x003D


[CSCdj82427]





lane fixed-config-atm-address
lane auto-config-atm-address





A message of the following form will be generated:


%LANE-4-LECS_WARN: ATM1/0: can't register
47.00790000000000000 0000000.00A03E000001.00 with signalling
(duplicate address ?)


As a workaround, use only a single LECS address configuration or do not enable logging timestamps if multiple LECS addresses are required. [CSCdj83816]





%SYS-3-INVMEMINT: Invalid memory action (malloc) at interrupt level
-Traceback= 6014B948 6014BEDC 6020BEB0 6020BFB0 60207048 60217C0C 6021A53C 6020BC20 601C0454 601C054C 601C0CBC 601BF650
%SYS-2-MALLOCFAIL: Memory allocation of 352 bytes failed from 0x6014BED4, pool Processor, alignment 0
-Process= "<interrupt level>", ipl= 6
-Traceback= 6014A2D8 6014BB64 6014BEDC 6020BEB0 6020BFB0 60207048 60217C0C 6021A53C 6020BC20 601C0454 601C054C 601C0CBC 601BF650


These messages may repeat, and the RSP may also hang as a result. An image with CSCdj85257 integrated in will resolve these secondary problems and the RSP will recover normally. CSCdj85257 will not resolve the original CyBus error, however. [CSCdj85257]





When running an image that has CSCdj93505 integrated into it, crash output for VIP2 products with a signal value of 20 indicates that a cache parity error condition was detected.


%VIP2 R5K-1-MSG: slot3 System Reload called from 0x..., context=0x...
%VIP2 R5K-1-MSG: slot3 System exception: sig=20, code=0x..., context=0x...


When this signal is present, the contents of the VIP crashinfo file are required for proper analysis.


When running an image that does not have CSCdj93505 integrated into it, the parity error may manifest in different ways. CSCdj20187 documents one such example. [CSCdj93505]





 Caveats for Release 11.1(1) through 11.1(17)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(17). These caveats also apply to Releases 11.1(1) through 11.1(16) (unless otherwise noted).


 For more caveats of Release  11.1(17) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(18).


 Basic System Services



This method is better than having to enter the test rsp cache memd uncached EXEC command every time the router is booted.


This configuration command can be used as a workaround for problems like CSCdj52309 and CSCdj70296.


To restore the MEMD caching policy to the original write-through policy, issue the memory cache-policy io write-through command. To determine what memory cache policies are currently configured on your router, use the show rsp command. [CSCdj33812]





 IBM Connectivity



 Interfaces and Bridging



For example, on a Cisco 7200 series router with Fast Ethernet port adapter 6/0, the problem looks like the following:


configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
int f 6/0
media ?
MII Use MII connector <--- Only MII, no RJ45


This problem appears on the following platforms in the specified Cisco IOS releases:


A workaround is available on most of the platforms and Cisco IOS images; to configure for RJ45, use the no media-type MII command. The following is an example of the workaround on a Cisco  7500 series router with Fast Ethernet port adapter 0/0/0:


configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
int f 0/0/0
no media MII <--- switch to RJ45


This workaround is available on the following platforms running the specified Cisco IOS releases:


Platform defaults are correctly preserved for all platforms and images that default to RJ45. The following platforms running the specified releases default to RJ45:


This problem first appeared in the following releases: 11.1(16.2), 11.1(15.3)CA, 11.2(10.4), 11.2(10.4)P, 11.3(1.2), and 11.3(1.2)T.


This problem was fixed in the following releases: 11.1(17.1), 11.1(17)CA, 11.2(11.4), 11.2(11.4)P, 11.3(1.5), and 11.3(1.5)T. [CSCdj75983]





As a workaround, use the PA-FE-TX or PA-FE-FX interfaces for ISL traffic or use Releases 11.3(1) or 11.3(1)T. [CSCdj79992]




 IP Routing Protocols



 TCP/IP Host-Mode Services



 Wide-Area Networking



In the case of multiple AIPs, change them one at a time. In the case of only one AIP, insert the new AIP before extracting the existing AIP. [CSCdj71438]





 Caveats for Release 11.1(1) through 11.1(16)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(16). These caveats also apply to Releases 11.1(1) through 11.1(15) (unless otherwise noted).


 For more caveats of Release  11.1(16) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(17).


 Basic System Services



For example, a problem was found with a Cisco  7500 series using a large number of Fast Ethernet and/or Ethernet interfaces and one or more FDDI interfaces. The pool of packet memory should have allocated 80 percent of the memory to the Ethernet and Fast Ethernet interfaces, which use an MTU of 1536. Instead it received 20 percent of the memory, and the lone FDDI interface with MTU  4512 got 80 percent of the packet memory.


The problem occurred with 55 Ethernet, 6 Fast Ethernet, and 1 FDDI network interfaces. The problem did not occur with fewer interfaces, specifically 36 Ethernet, 5 Fast Ethernet, and 1 FDDI interfaces.


The problem may show up as a high number of input drops on some router interfaces. [CSCdj55428]




 IBM Connectivity



The problem typically occurs when NetBIOS is utilized to allow workstations to communicate between Ethernet and Token Ring. It will also occur when SNA is used.


The workaround is to disable fast switching by using the command no source-bridge transparent fastswitch or configure the end stations to use frames with a payload of less than or equal to 1500 bytes. [CSCdj62385]





[abort(0x601f2c3c)+0x8]
[crashdump(0x601f0b20)+0x94]
[process_handle_watchdog(0x601c2f08)+0xb4]
[signal_receive(0x601b7d58)+0xa8]
[process_forced_here(0x60169424)+0x68]
[locate_node_index(0x607dbcc0)+0x64]
[etext(0x60849e00)+0xcbee04]


[CSCdj67966]





RA: 0x607E1724[find_matching_row(0x607e16ec)+0x38] RA: 0x607E1B9C[Tfind_next(0x607e1b70)+0x2c] RA: 0x6071182C[DBfind_next_directory_entry(0x60711814)+0x18] RA: 0x6070BAD8[CPdelete_men(0x6070ba90)+0x48] RA: 0x6070BA78[CPupdate_cp_status(0x6070b9c0)+0xb8] RA: 0x6070B40C[CPmain(0x6070b300)+0x10c] RA: 0x6070AC2C[newdss00(0x6070ab60)+0xcc] RA: 0x60183F80[r4k_process_dispatch(0x60183f6c)+0x14]


[CSCdj70817]





 Interfaces and Bridging



A workaround for the second problem is to turn off CDP globally or on individual interfaces. In this case, the user can turn off CDP on the serial interface before adding or removing subinterfaces. [CSCdj07291]





This problem should have minimal impact on the performance of a multidrop line because a FEP usually resorts to individual polling. [CSCdj33392]





The problem only affects the mid-range and low-end platforms. [CSCdj41666]





buffers big min-free 5 buffers large max-free 10 buffers huge max-free 4 [CSCdj50120]




 IP Routing Protocols



The router can be forced to install the matching route by using the clear ip route * command. [CSCdj32471]





This issue occurs when the Proteon router's Internal Address is advertised as a Host Route, not a network, in the router's LSA. A Host Route is represented as a Type 3 link (Stub Network) whose link ID is the host's IP address and whose Link Data is a mask of all ones (0xffffffff). This Host Route is advertised into all OSPF areas. [CSCdj56079]





The nature of the defect is that it will only occur after a dynamic event. If redistribution is manually configured, EIGRP will initially reflect correct information in the topology table; however, after any sort of dynamic event, the topology table becomes invalid and routing updates sent are inaccurate. [CSCdj58676]





Incoming packets on the ATM interface and outgoing packets on the serial interface also experience this problem. However, incoming packets on the serial interface and outgoing packets on the ATM interface do not experience this problem.


It seems that incoming packets are not fast switched. [CSCdj59076]





 TCP/IP Host-Mode Services



For in-depth information including workarounds and information on other Cisco product vulnerabilities, refer to the following URL:


http://www.cisco.com/warp/customer/770/land-pub.shtml  [CSCdj61324]




 Wide-Area Networking



During normal behavior, the point-to-point subinterface should go down when the primary DLCI fails. If a secondary DLCI fails, the subinterface stays up, but traffic destined for that DLCI only will fail. [CSCdj11056]





The workaround is to remove the ip tcp header-compression or ppp multilink command. [CSCdj53093]





 Caveats for Release 11.1(1) through 11.1(15)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(15). These caveats also apply to Releases 11.1(1) through 11.1(14) (unless otherwise noted).


 For more caveats of Release  11.1(15) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(16).


 Basic System Services



In particular, the enqueue and the dequeue routines are not reset and this causes the box to crash when the routines are invoked the next time. Once the box is rebooted, the inconsistency is cleared. [CSCdj29439]





The following are known workarounds:


- Increase the input queue to 175. ([75]Original Queue amount+[100] per exception dump x.x.x.x command)


- Remove the exception dump x.x.x.x command.


[CSCdj58035]




 EXEC and Configuration Parser



 IBM Connectivity



There is no known workaround. [CSCdj25859]





System was restarted by bus error at PC 0x8B5902, address 0x4AFC4AFC PC: process_snmp_trs_tg_inc


0x8B5CAC:_process_ms_data_req_trs(0x8b5aaa)+0x202 0x87E5FE:_xxxtos00(0x87d6b0)+0xf4e 0x180E5C:_process_hari_kari(0x180e5c)+0x0 [CSCdj36824]





System was restarted by bus error at PC 0x3784864, address 0xF0110208 PC 0x3784864[_Qfind_front(0x3040a04+0x743e44)+0x1c] RA: 0x36C1F2E[_queue_find_front(0x3040a04+0x68151c)+0xe] RA: 0x36CC554[_psbmfrm(0x3040a04+0x68bb30)+0x20] RA: 0x36CDAF6[_psp00(0x3040a04+0x68cfd4)+0x11e] RA: 0x314BD78[_process_hari_kari(0x3040a04+0x10b374)+0x0]


[CSCdj44198]





[CSCdj47941]





The workaround is not to reconfigure virtual rings or remote peers while executing a show source command. [CSCdj49973]





 Interfaces and Bridging



 IP Routing Protocols



System restarted by error - an arithmetic exception, PC 0x60286234


The program counter value points to an EIGRP IOS routine. [CSCdj38361]





This problem exists in all Cisco IOS releases starting at Release 10.3. The problem will be fixed in Release 11.1 and newer releases. [CSCdj53804]





 ISO CLNS



 Novell IPX, XNS, and Apollo Domain



 TCP/IP Host-Mode Services



 Wide-Area Networking



%SYS-3-INVMEMINT: Invalid memory action (free) at interrupt level


[CSCdj42341]





 Caveats for Release 11.1(1) through 11.1(14)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(14). These caveats also apply to Releases 11.1(1) through 11.1(13) (unless otherwise noted).


 For more caveats of Release  11.1(14) and earlier 11.1 releases, see the preceding section, "Caveats for Release 11.1(1) through 11.1(18)."


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(15).


 AppleTalk



 Basic System Services



The workaround is to use the copy tftp flash command line interface command. This CLI command invokes the FLH interface and the file is copied successfully to the device. [CSCdj27438]





APPN-DLUR-MIB
IBM-6611-APPN-MIB
CISCO-CIPCSNA-MIB
CISCO-CIPLAN-MIB
CISCO-CIPTCPIP-MIB
CISCO-SNA-LLC-MIB
SNA-NAU-MIB
CISCO-TN3270SERVER-MIB
OLD-CISCO-IP-MIB
BGP4-MIB
LAN-EMULATION-CLIENT-MIB
RFC1406-MIB
RMON-MIB
IF-MIB
RFC1398-MIB
OLD-CISCO-INTERFACES-MIB
CISCO-PING-MIB
CISCO-QLLC01-MIB [CSCdj34766]





 IBM Connectivity



The problem is related to the way DLSw backup peers are configured. This problem only occurs if the local router is configured with backup peer commands and the remote router also has a configured peer and is not promiscuous.


The workaround is to remove the DLSw backup peer configuration. [CSCdj21664]





If the downstream device never responds to the outstanding bind, the DLUR router will wait indefinitely and not free the local-form session ID (lfsid). This may cause a situation in which the host tries to reuse a lfsid after it has sent an unbind request, but the DLUR rejects the new bind request because it believes that this lfsid is in use. If the host continuously tries to use this lfsid which the DLUR believes is in use, then no new sessions can be established. This problem occurs only when the downstream device does not respond to a bind request. [CSCdj30386]





%APPN-6-APPNSENDMSG: Ended DLUR connection with DLUS NETA.SJMVS1


%APPN-7-MSALERT: Alert LU62004 issued with sense code 0x8A00008 by XXXSMPUN


%APPN-6-APPNSENDMSG: Starting DLUR connection with DLUS NETA.SJMVS4


%APPN-7-APPNETERROR: CP_STATUS FSM: Unanticipated CP_STATUS message received


Each subsequent broadcast locate received by the router causes the following messages to be displayed and about 1920 bytes of APPN memory to be leaked:


%APPN-7-APPNETERROR: MAP_INPUT_SET_TO_ROW: invalid input value=0x80200080


%APPN-7-APPNETERROR: State Error lcb: 60C05CC0 pcid: DA839C70FB1548CB row: 22 col: 0


This problem occurs when two links are active to the same node, the CP-CP sessions are split between these two links, and the link with contention loser is stopped.


The APPN subsystem should be stopped and restarted to clear this problem. If the CP-CP sessions are between the router and the host, terminating either CP-CP session on the host will also clear this problem. [CSCdj33718]





A workaround is to remove any remwait/dead peer statements. [CSCdj42427]





System was restarted by error - a Software forced crash, PC 0x60278214


The protocols running on the router are RSRB, DLSw, DECnet, and IPX. [CSCdj42431]





System was restarted by bus error at PC 0x3784864, address 0xF0110208 PC 0x3784864[_Qfind_front(0x3040a04+0x743e44)+0x1c] RA: 0x36C1F2E[_queue_find_front(0x3040a04+0x68151c)+0xe] RA: 0x36CC554[_psbmfrm(0x3040a04+0x68bb30)+0x20] RA: 0x36CDAF6[_psp00(0x3040a04+0x68cfd4)+0x11e] RA: 0x314BD78[_process_hari_kari(0x3040a04+0x10b374)+0x0] [CSCdj44198]





 Interfaces and Bridging



As a result, the first ICMP ARP broadcast message fails to reach the destination when ping is used. [CSCdj21365]





The encapsulation fddi command should only be used with bridging enabled.


A workaround is to use the no bridge-group 1 command to disable bridging. [CSCdj24479]





The workaround is to use RFC1483 over a PVC using a multipoint subinterface with a map list defined. Using the map-group command on a multipoint subinterface does not exhibit breakage.


To determine if you have this bug, enter the show arp command. If there is an entry for the other end of the PVC showing "incomplete" for the MAC address, then you are affected by this caveat. [CSCdj34217]





 IP Routing Protocols



The workaround is not to enter a key longer than 19 characters, either encrypted or not.


The same problem happens with the ip ospf message-digest key-id md5 key command. In this case, the key length should not be longer than 36 characters. [CSCdj37583]





A workaround is to configure the loopback interface, whose address is greater than any other address on the router. [CSCdj37962]




 LAT



%LAT-3-BADDATA: Tty124, Data pointer does not correspond to current packet


When many LAT sessions are active, and a received data slot starts in the last 14 bytes of a full Ethernet frame, data for that slot is discarded. [CSCdi82343]




 Novell IPX, XNS, and Apollo Domain



 TCP/IP Host-Mode Services



 VINES



 Wide-Area Networking



In Cisco IOS Release 11.0(11) the software accepts the remote peer's "Her" proposed address regardless, and the "Her" address is subsequently added to the IP routing table as a host route.


With Cisco IOS releases later than 11.0(11) the software will check the "Her" address against the corresponding dialer map and if the address is different than the IP address detailed within the dialer map, a NAK will be sent and the dialer map IP address will be added as a host route in the IP routing table.


It is possible to revert to the previous operation using the hidden interface command ppp ipcp accept-address. When enabled the peer IP address will be accepted but is still subject to AAA verification, it will have precedence over any local address pool however. [CSCdj04128]





 Caveats for Release 11.1(1) through 11.1(13)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(13). These caveats also apply to Releases 11.1(1) through 11.1(12) (unless otherwise noted).


 For more caveats of Release  11.1(13) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(14).


 AppleTalk



 Basic System Services



To work around this problem, do one of the following:





This problem occurs because of a race condition when doing DNS name query and DNS name cache is removed in the middle of the process.


There is no workaround on the router side. On the DNS server side, configuring DNS TTL to be one minute or longer may work around this problem. However, this workaround may not be acceptable for some applications. [CSCdj16824]





To run type A7, A6, or AA boot Flash devices and use images prior to this bug fix, format boot Flash with an image containing this bug fix. Then load an older image onto the newly formatted boot Flash SIMM. [CSCdj20681]





 IBM Connectivity



PC= 0x606079a4[psbmfrm(0x60607930)+0x74], 32 bytes


PC= 0x606094d0[psp00(0x60609380)+0x150], 320 bytes [CSCdj25484]





606CD174[Qfind_front+0x24]


606C7D80[timer_process+0x300]


606C8070[csweotsk+0x1d0]


A router may experience this problem after displaying several messages when the output buffer was full. If the crash was related to displaying "incomplete definition in configuration" warnings, the workaround is too remove these incomplete definitions. [CSCdj26701]





Because other network events (link outages, and so forth) can trigger a node to send a TDU, this problem will not necessarily appear exactly after a 60-day uptime -- it may occur much later or not at all. However, any APPN router running in the network for over 60 days is at risk for seeing this problem.


Stopping and restarting APPN will work around this problem until the next timer wrap, which can be up to 45 days, but may be less depending on the current value of the timer. Reloading the router will reset the timer and avoid the problem for an additional 60 days. [CSCdj29014]





Caveat CSCdi77040 provides a fix for this problem in the system side. This caveat provides the corresponding fix for APPN. [CSCdj30552]





When memory is exhausted, the APPN subsystem may stop or the router may reload. [CSCdj33429]




 Interfaces and Bridging



%RSP-3-IP_PANIC: Panic: Serial12/2 800003E8 00000120 0000800D 0000534C


%DBUS-3-CXBUSERR: Slot 12, CBus Error


%RSP-3-RESTART: cbus complex


If the string "0000800D" is included in the panic message, the problem is related to this bug. The workaround is to load a new image that contains the fix for this bug. [CSCdi78086]





 IP Routing Protocols



By design, an extended access list can not be used as a condition to originate a default.


A workaround (the right approach) is to use a standard access list in default origination. [CSCdj02583]





The workaround is to turn on IP routing and then assign the IP addresses to the interfaces. [CSCdj26052]





 ISO CLNS



 LAT



 Novell IPX, XNS, and Apollo Domain



 TCP/IP Host-Mode Services



The workaround is to disable both syslog and SNMP traps. The commands to do this are no snmp-server host ip-address and no logging ip-address. [CSCdj27567]





 VINES



 Wide-Area Networking



A workaround for this is to use ppp authentication and autoselect ppp on the lines. [CSCdj14047]





The following are indicators that may be used to determine if the AS5200 is encountering this problem:


%SYS-2-MALLOCFAIL: Memory allocation of 1056 bytes failed from 0x2214E776, pool Processor, alignment 0 -Process= "Net Periodic", ipl= 0, pid= 34 -Traceback= 2214D3E0 2214E542 2214E77E 2214BEC6 2214C12A 22159466 2215E86E 22140BDE 2213B688 2213B6E0




[CSCdj21944]





To work around this problem, use the async mode dedicated command if no login is required. If a login is required, configure the no flush-at-activation command, change the q2 register in the modem database, and configure the modem autoconfigure type command. [CSCdj25443]





The following error message can be seen scrolling on the console if the router is in the above state:


%X25-4-VCLOSTSYNC: Interface TCP/PVC, VC 0 TCP connection corrupted


This does not seem to occur in a normal XOT switching environment. [CSCdj25846]





The workaround is to configure the asynchronous interfaces using the async mode dedicated command. Sometimes, adding a second or two delay in the automated dialer's script also fixes the problem. [CSCdj26647]




 Caveats for Release 11.1(1) through 11.1(12)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(12). These caveats also apply to Releases 11.1(1) through 11.1(11) (unless otherwise noted).


 For more caveats of Release  11.1(12) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(13).


 AppleTalk



 Basic System Services



 IBM Connectivity



In some application environments, certain 3270 emulators will not direct a test poll to a specific media access control address and will use an all Fs address to create the frame. It is this all Fs frame in an SRB configuration that will not be forwarded by the router. This configuration impacts workstations that are attempting to connect to host devices. The broadcast frame will never leave the local ring.


Most emulators will use the destination media access control address of the host device to create a frame containing the test poll. With some proprietary implementations, the MAC address of the host device does not have to be known by the end device. [CSCdj13563]





A workaround is to ensure there are no unnecessary PUs configured on a line that is continually sending SNRMs. [CSCdj17630]





 Interfaces and Bridging



%CBUS-3-CMDTIMEOUT: Cmd timed out, CCB 0x5800FF50, slot x, cmd code 0


A possible workaround is to issue a microcode reload command or load a new system image that has the fix for this bug. [CSCdj00013]





 IP Routing Protocols



 LAT



 Novell IPX, XNS, and Apollo Domain



 TCP/IP Host-Mode Services



 Wide-Area Networking



%AIP-3-AIPREJCMD: Interface ATM3/0, AIP driver rejected Teardown VC command (error code 0x8000)


The workaround is to reload the system. [CSCdj20667]





A possible workaround is to reload the microcode. [CSCdj21639]





 Caveats for Release 11.1(1) through 11.1(11)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(11). These caveats also apply to Releases 11.1(1) through 11.1(10) (unless otherwise noted).


 For more caveats of Release  11.1(11) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(12).


 AppleTalk



 Basic System Services



A workaround is to enter the command test rsp cache memd-fastswitchuncache each time the router is rebooted. [CSCdj10028]





 IBM Connectivity



This problem may cause VTAM to refuse to activate subsequent DLUR/DLUS pipes for all DLUR NNs. "/d net, dlurs" shows the DLUS conwinner state as reset and the conloser state as active.


To prevent the DLUR router from sending this corrupt frame, reconfigure the DLUR routers without coding a backup DLUS. [CSCdj10485]





 Interfaces and Bridging



 IP Routing Protocols



 Novell IPX, XNS, and Apollo Domain



 Protocol Translation



 TCP/IP Host-Mode Services



Mar 19 08:41:23: %TCP-2-BADREFCNT: Tty0: Bad refcnt for packet 0x608F9C2C during retransmit, 135.135.100.1:1998 to 135.135.105.1:11000, state 4-Traceback= 601EEB7C 601EEEA4 601F1B68 601F1E4C 6013F140 6013F12C
Mar 19 08:41:50: %X25-4-VCLOSTSYNC: Interface Serial3, VC 82 TCP connection corrupted
Mar 19 08:41:52:TCP0: extra packet reference for pak 0x60A031D8 found:
Mar 19 08:41:52: %TCP-2-BADQUEUE: Multiple entry for packet 60A031D8-Process= "TCP Driver", ipl= 0, pid= 26-Traceback= 601F3384 601F5408 6023CCB4 6023D214 6013F140 6013F12C
Mar 19 08:41:52: pak: 135.135.100.1:1998, 135.135.1.4:11137, seq 1668710213length 47
Mar 19 08:41:52: TCB: 135.135.100.1:1998, 135.135.1.13:11137, sendnext 1668710220, state 4[CSCdj06781]





 Wide-Area Networking



 Caveats for Release 11.1(1) through 11.1(10)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(10). These caveats also apply to Releases 11.1(1) through 11.1(9) (unless otherwise noted).


 For more caveats of Release  11.1(10) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(11).


 Basic System Services



The hold-queue command is intended to configure the number of output hold queue buffers for FIFO (or FCFS) queueing. It has no meaning in the context of fair queueing. So the (intentional) design was that this command would be ignored when fair queueing was enabled.


When fair queuing has been configured, you may use the fair-queue command to control the number of output buffers which may be used by fair queuing. [CSCdj01870]





 EXEC and Configuration Parser



 IBM Connectivity



IPS ID: 1400 QUEUE: 2 ORIGIN: xxxpcs00 MUTYPE: C5
%APPN-0-APPNEMERG: Assertion failed in ../scm/xxximndr.c at line 158
-Process= "xxxims00", ipl= 0, pid= 58
-Traceback= 606C3488 606879EC 606818C8 606810E4 6067AF90 6019AB08 6019AAF4



[CSCdi90117]





 Interfaces and Bridging



*Dec 20 06:53:08: %RSP-3-ERROR: CyBus0 error 78
*Dec 20 06:53:08: %RSP-3-ERROR: invalid page map register
*Dec 20 06:53:08: %RSP-3-ERROR: command/address mismatch
*Dec 20 06:53:08: %RSP-3-ERROR: invalid command
*Dec 20 06:53:08: %RSP-3-ERROR: address parity error
*Dec 20 06:53:08: %RSP-3-ERROR: address parity error 23:16 1, 15:8 1, 7:0 1
*Dec 20 06:53:08: %RSP-3-ERROR: bus command invalid (0xF)
*Dec 20 06:53:08: %RSP-3-ERROR: address offset (bits 3:1) 14
*Dec 20 06:53:08: %RSP-3-ERROR: virtual address (bits 23:17) FE0000
*Dec 20 06:53:09: %RSP-3-RESTART: cbus complex




or




09:53:32.607 EST: %RSP-3-ERROR: MD error 0080008030003000
09:53:32.607 EST: %RSP-3-ERROR: SRAM parity error (bytes 0:7) 0F
09:53:33.363 EST: %RSP-3-RESTART: cbus complex




Such CyBus errors with code 78 and that point to a virtual address FE0000 or have MD errors similar to the above have two known causes. First, if there are HIPs in the router and on the bus reporting the CyBus error, if applicable, there is a race condition with the HIP microcode on an oversubscribed bus. The workaround on dual-CyBus platforms is to move all the HIPs onto a CyBus that is not oversubscribed. Second, these errors can be caused by the failure of a marginal CI arbiter board or an RSP board. As a result of this problem, all interfaces are reset, causing forwarding to be stopped for a few seconds. [CSCdj06566]




 IP Routing Protocols



System was restarted by bus error at PC 0x601E4CD0, address 0xD0D0D0D
4500 Software (C4500-P-M), Version 10.3(16), RELEASE SOFTWARE (fc1)
Compiled Thu 24-Oct-96 18:32 by richardd (current version)
Image text-base: 0x600087E0, data-base: 0x60370000

Stack trace from system failure:
FP: 0x605D46B8, RA: 0x601E4CD0
FP: 0x605D46D8, RA: 0x601E4D88
FP: 0x605D46F8, RA: 0x601E50EC
FP: 0x605D4710, RA: 0x601C88E0
FP: 0x605D4740, RA: 0x601E4998
FP: 0x605D4760, RA: 0x601E5174
FP: 0x605D4778, RA: 0x60081D04
FP: 0x605D47B8, RA: 0x6006C8A4



This trace decodes as follows:




Symbols :
nhrp_cache_clear_nei
nhrp_cache_clear_nei
nhrp_cache_delete_subr
nhrp_cache_age_subr
rn_walktree_blocking_list
nhrp_cache_walk
nhrp_cache_age
registry_list
net_oneminute




[CSCdi90523]





 Novell IPX, XNS, and Apollo Domain



 TCP/IP Host-Mode Services



show ip traffic will show ICMP Time Exceeded counter incrementing.




A workaround is to turn off TCP header compression. [CSCdj01681]




 Wide-Area Networking



%AAAA-3-BADSTR: Bad accounting data: too many attributes




[CSCdj00190]





 Caveats for Release 11.1(1) through 11.1(9)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(9). These caveats also apply to Releases 11.1(1) through 11.1(8) (unless otherwise noted).


 For more caveats of Release  11.1(9) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(10).


 Basic System Services



%AAAA-3-BADSTR: Bad accounting data: too many attributes




[CSCdj00190]





 DECnet



 EXEC and Configuration Parser



 IBM Connectivity



 Interfaces and Bridging



For example, if the table has the entries with indices of 0000.0000.0001 0000.0000.0002 0000.0000.0003 0000.0000.0005, a GetNext of 0000.0000.0002 would return the index 0000.0000.0005, because 0000.0000.0003 is the index requested + 1. A GetNext of 0000.0000.0003 would return the index 0000.0000.0005, because 0000.0000.0005 is greater than the requested index + 1. [CSCdi84559]




 IP Routing Protocols



 ISO CLNS



 Novell IPX, XNS, and Apollo Domain



 TCP/IP Host-Mode Services



 VINES



 Wide-Area Networking



 Caveats for Release 11.1(1) through 11.1(8)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(8). These caveats also apply to Releases 11.1(1) through 11.1(7) (unless otherwise noted).


 For more caveats of Release  11.1(8) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(9).


 AppleTalk



 Basic System Services



Encapsulated bridging does not work on a Cisco 7500 series router. To bridge between an AGS+ and a Cisco 7500 series router, you must use CSC-C2FCIT cards in the AGS+ and translational bridging.


The big disadvantage of using encapsulated bridging is that it cannot use the hardware bridge filtering capabilities of the CSC-C2FCIT cards, which have a CAM built into them that is used to do bridge filtering on the card. When encapsulated bridging is used, the main processor must do all bridge filtering. This means that one busy encapsulated bridging FDDI network can consume the entire bandwidth of the router's main processor, just for bridge filtering. Therefore, Cisco discourages the use of encapsulated bridging. [CSCdi46862]





%SYS-3-TIMERNEG: Cannot start timer (0x1E4388) with negative offset (-495928).
-Process= "Per-minute Jobs", ipl= 0, pid= 37
-Traceback= 22157D7A 22154320 221A17EA 2215F45C 2213E074




High CPU utilization might occur prior to this message and the reload. [CSCdi76126]





 IBM Connectivity



%CLS-3-CLSFAIL: CLS: Assertion failed: file "../srt/qllc.c", line 4352 !"QSapAddCepFailed".




[CSCdi64840]





Using the debug dlsw reachability or debug dlsw reachability error commands will indicate an "lf" mismatch condition detected by DLSw. This condition should not be flagged as an error. The smallest "lf" across the entire path should be used for the circuit. [CSCdi77805]





 Interfaces and Bridging



 IP Routing Protocols



System restarted by error - Zero Divide, PC 0x38EF0C (0x38EF0C:_igmp_report_delay(0x38eec6)+0x46)




[CSCdi83040]





 ISO CLNS



 Novell IPX, XNS, and Apollo Domain



 TCP/IP Host-Mode Services



 Wide-Area Networking



CBUS-3-CMD: Cmd failed: global ptrs, response 0x8010, AIP1 CBUS-3-AIPRSET: Interface ATM1/0, Error (8010) select - aip_reset() CBUS-3-AIPRSETU: Unit 32, Error (8010) enable - aip_reset()



The workaround is to reload the router. [CSCdi75659]





 Caveats for Release 11.1(1) through 11.1(7)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(7). These caveats also apply to Releases 11.1(1) through 11.1(6) (unless otherwise noted).


 For more caveats of Release  11.1(7) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(8).


 Basic System Services



To avoid this problem, you should upgrade all IOS Release  11.1 RSP-based systems to Cisco  IOS Release  11.1(8), or a later 11.1 release.


For those systems that cannot be upgraded, you can avoid this problem by disabling Backing Store, Fair Queuing, and UDP turbo flooding.


Disable Backing Store and Fair Queuing on each interface with the commands no transmit-buffers backing-store and no fair-queue. Backing Store defaulted to OFF in images beginning with 11.1(4.1). However, it is important to look at the current configuration. An image configured before Backing Store defaulted to OFF may have it ON for router interfaces.


Disabling UDP turbo flooding is a workaround required for 11.0 and later major releases. UDP turbo flooding is OFF by default in all releases, however, you should ensure that it is turned OFF in the current configuration. The command to disable UDP turbo flooding is no ip forward-protocol turbo-flood.


[CSCdi71609]





%SYS-3-TIMERNEG: Cannot start timer (0x1E4388) with negative offset (-495928). -Process= "Per-minute Jobs", ipl= 0, pid= 37 -Traceback= 22157D7A 22154320 221A17EA 2215F45C 2213E074




High CPU utilization may be seen prior to message and reload. [CSCdi76126]




 EXEC and Configuration Parser



 IBM Connectivity



ALIGN-1-FATAL: Illegal access to a low address addr=0x1, pc=0x60544FE0, ra=0x60544FE8, sp=0x60AEE780
*** System received a SegV exception ***
signal= 0xb, code= 0x8000200c, context= 0x60a1a980 PC = 0x6010bfd4, Cause = 0x2020, Status Reg = 0x34008002
DCL Masked Interrupt Register = 0x00000000
DCL Interrupt Value Register = 0x00000000
MEMD Int 6 Status Register = 0x00000000
System was restarted by error - a SegV exception, PC 0x60544FE0




The workaround is to not use the Token Ring interfaces on the VIP. [CSCdi69234]





Exception: Line 1111 Emulator at 0x7E9500 (PC)




[CSCdi73675]





 Interfaces and Bridging



In addition, if VIP Ethernet is used with multiple unicast protocols such as HSRP, packet duplication can occur on the LAN segment. These problems can significantly degrade RSP performance. [CSCdi71856]





Spanning Tree BPDUs are handled by small buffers. If a BPDU that was handled in a small buffer is used at the same time the interface is going down, this small buffer will erroneously not be released. [CSCdi72783]





%CBUS-3-CMDTIMEOUT: Cmd timed out, CCB 0x5800FF50, slot x, cmd code 0




The show diag x command reports that the board is disabled (wedged). The show version command does not show the card in the specified slot. The write terminal command does not show the configuration for the card in the slot. A possible workaround is to issue a microcode reload command or to load a new system image that has the fix for this bug. [CSCdi73130]




 IP Routing Protocols



 ISO CLNS



 Novell IPX, XNS, and Apollo Domain



 TCP/IP Host-Mode Services



 Wide-Area Networking



 Caveats for Release 11.1(1) through 11.1(6)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(6). These caveats also apply to Releases 11.1(1) through 11.1(5) (unless otherwise noted).


 For more caveats of Release  11.1(6) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(7).


 AppleTalk



 Basic System Services



 DECnet



 EXEC and Configuration Parser



 IBM Connectivity



%CBUS-3-CIPRSET: Interface Channelslot/port, Error (8010) disable - cip_reset() %CBUS-3-INITERR: Interface decimal, Error (8004), idb hex decimal cmd_select - cbus_init() %CBUS-3-INITERR: Interface decimal, Error (8004), idb hex decimal cmd_select -cbus_init() %CBUS-3-CTRLRCMDFAIL1: Controller decimal, cmd (128 hex) failed (0x8010)count (16) %CBUS-3-FCICMDFAIL1: Controller decimal, cmd (32 0x00000001) failed (0x8010) count (1)




Looping may be severe enough to require a router reboot.


The looping messages may overrun the logging buffer and thus obviate the reason for the initial attempt to reset the CIP. [CSCdi66420]





 Interfaces and Bridging



%CBUS-3-CMDTIMEOUT: Cmd timed out, CCB 0x5800FF50, slot x, cmd code 0




The show diagnostics x command reports that the board is disabled, the show version command does not show the card in the specified slot, the write terminal command does not show the configuration for the card in the slot. A possible workaround is to issue a microcode reload command or load a new system image that has the fix for this bug. [CSCdi66450]





 IP Routing Protocols



The workaround is to not set the dead-interval the same as the original default.


When the fixed image is first loaded, the problem still happens. To resolve the problem, reconfigure the dead-interval again and perform a write memory operation. [CSCdi62640]





 Novell IPX, XNS, and Apollo Domain



 TCP/IP Host-Mode Services



 Wide-Area Networking



 Caveats for Release 11.1(1) through 11.1(5)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(5). These caveats also apply to Releases 11.1(1) through 11.1(4) (unless otherwise noted). For more caveats of Release  11.1(5) and earlier 11.1 releases, see all the preceding caveat sections. Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document. All the caveats listed in this section are resolved in Release  11.1(6).


 Additionally, one caveat was resolved in a special release prior to Release  11.1(6), as well as in Release  11.1(6). This special release was named 11.1(5a) and is described in the following paragraphs.


 Cisco  IOS Release  11.1(5a)


 The Cisco  IOS Release  11.1(5) rsp- images were rebuilt to include a single defect fix, and were renumbered to 11.1(5a). The defect is bug CSCdi66673 and is described as follows:


 When Ethernet runt packets are received by Cisco 7500 series router processors (RSP1, RSP2, or RSP7000), a Reserved Exception crash or a QAERROR error will occur. When either of these problems happens, a switching complex restart is forced. The Reserved Exception crash has the following output:


Queued messages:
Aug 14 10:44:16: %RSP-3-ERROR: memd write exception, addr 08000000
Aug 14 10:44:16: %RSP-3-ERROR:   RSP alignment error on write to QA, addr 080000
00
*** System received a reserved exception ***
signal= 0x9, code= 0x0, context= 0x60c72fd0
PC = 0x60107514, Cause = 0x2020, Status Reg = 0x34008702
DCL Masked Interrupt Register = 0x000000ff
DCL Interrupt Value Register = 0x00000000
MEMD Int 6 Status Register = 0x00000000




 The QAERROR error has the following output:


Jun 17 10:50:23.329: %RSP-2-QAERROR: reused or zero link error, write at addr 03
08 (QA)
  log 260308C0, data A816FFFF 00000000






 Access Server



 AppleTalk



 Basic System Services



%DBUS-3-DBUSINTERR: Slot 0, Internal Error




The message may also be accompanied by the following:




%CBUS-3-CMDTIMEOUT: Cmd time out, CCB 0xXXXXXXXX slot n, cmd code n

%DBUS-3-WCSLDERR: Slot n, error loading WCS, status 0xXX cmd/data 0xXX pos n




If the WCSLDERR error occurs, the board is effectively disabled and is not displayed when you issue a write terminal command. Issue a microcode reload command to take the card out of the disabled state. [CSCdi49854]





Queued messages:
Aug 14 10:44:16: %RSP-3-ERROR: memd write exception, addr 08000000
Aug 14 10:44:16: %RSP-3-ERROR:   RSP alignment error on write to QA, addr 080000
00
*** System received a reserved exception ***
signal= 0x9, code= 0x0, context= 0x60c72fd0
PC = 0x60107514, Cause = 0x2020, Status Reg = 0x34008702
DCL Masked Interrupt Register = 0x000000ff
DCL Interrupt Value Register = 0x00000000
MEMD Int 6 Status Register = 0x00000000




The QAERROR error has the following output:




Jun 17 10:50:23.329: %RSP-2-QAERROR: reused or zero link error, write at addr 03
08 (QA)
  log 260308C0, data A816FFFF 00000000




[CSCdi66673]





 IBM Connectivity



This problem was introduced by some changes to the Token Ring interrupt handler in Release  11.0 and later.


There is no workaround for the diversion, though the flushing can be avoided by raising the explorer maxrate value to some high number. However, this may cause instability in the network. [CSCdi59090]





The following error messages occur:




*Aug 7 11:48:33 mst: %SYS-2-LINKED: Bad enqueue of 60AE6FC0 in queue 60B0EB60 -Process= "<interrupt level>", ipl= 5 -Traceback= 60110530 6016901C 60169070 60211C8C 600F2E70 600F2B70 600F06D4 601B78E0 60188EB0
boxer% rsym rsp-j-mz.111-5.0.1.symbols Reading rsp-j-mz.111-5.0.1.symbols rsp-j-mz.111-5.0.1.symbols read in Enter hex value: 60110530 0x60110530:p_enqueue(0x601104d0)+0x60 Enter hex value: 6016901C 0x6016901C:process_enqueue_common(0x60168fb4)+0x68 Enter hex value: 60169070 0x60169070:process_enqueue_pak(0x6016905c)+0x14 Enter hex value: 60211C8C 0x60211C8C:ip_simple_enqueue(0x60211c74)+0x18 Enter hex value: 600F2E70 0x600F2E70:dlsw_lan2fst(0x600f2c1c)+0x254 Enter hex value: 600F2B70 0x600F2B70:dlsw_srb_input(0x600f2ab0)+0xc0 Enter hex value: 600F06D4 0x600F06D4:fs_srb_to_vring(0x600f054c)+0x188 Enter hex value: 601B78E0 0x601B78E0:rsp_process_rawq(0x601b673c)+0x11a4 Enter hex value: 60188EB0 0x60188EB0:rsp_qa_intr(0x60188dec)+0xc4




Also, DLSw FST needs to be allowed over a Channel Interface Processor (CIP) LAN interface. [CSCdi65603]





%SYS-2-LINKED: Bad enqueue of 9600E8 in queue 88380. SNA: Alert xxxxx not sent, Focal point buffer overflowed.




[CSCdi66340]





 Interfaces and Bridging



PC2PR2#sh int s 4/1
Serial4/1 is down, line protocol is down
	   Hardware is cyBus Serial.
	   0 output buffer failures, 0 output buffers swapped out 0 carrier transitions
	   RTS up, CTS up, DTR up, DCD up, DSR up




Note that router reload is not necessary; two workarounds are known. If the first workaround is not successful at bringing up the interface, try the second.


Enter the cBus test mode and select the interface having the problem. Read a portion of the interface processor memory.


This example is for an FSIP interface at 2/0:






Router#test cb
RSP diagnostic console program
Enter slot number: [0x0]: 2
Enter interface number: [0x0]:
Command queue for slot 2 is 0x12.  CCB is 0xFF50
RSP (? for help) [?]: ri
Enter FSIP Mem starting address [0x0]:
Enter FSIP Mem ending address [0x20000]: 0x20
FSIP Mem 00000:  0001 FFFC
FSIP Mem 00004:  0000 01C6
FSIP Mem 00008:  0000 049A
FSIP Mem 0000C:  0000 049A
FSIP Mem 00010:  0000 049A
FSIP Mem 00014:  0000 049A
FSIP Mem 00018:  0000 049A
FSIP Mem 0001C:  0000 049A
FSIP Mem 00020:  0000 049A


This example is for the HIP at 1/0:




Router#test cb
RSP diagnostic console program
Enter slot number: [0x2]: 1
Enter interface number: [0x0]:
Command queue for slot 1 is 0x11.  CCB is 0xFF40
RSP (? for help) [?]: ri
Enter IP Mema starting address [0x0]:
Enter IP Mema ending address [0x10000]: 0x20
IP Mema 0000:  7FA2 7FA0 7FA4 0044  0005 0000 0000 0000
IP Mema 0008:  0000 0098 00D0 0080  0032 0000 0000 0000
IP Mema 0010:  FFFF 0001 0000 0003  0000 7EA0 7E98 7E90
IP Mema 0018:  0000 0000 0000 0000  0000 0003 0000 00DD


Router(config)#mic rel




[CSCdi57573]





 IP Routing Protocols



 Novell IPX, XNS, and Apollo Domain



 Protocol Translation



 VINES



 Wide-Area Networking



The error message "%SYS-2-INPUTQ: INPUTQ set, but no idb, ..." will appear.


A temporary workaround is configuring the interface level command: hold-queue 750 in until you are able to reload the router. Remove this configuration after upgrading the software. [CSCdi61629]





%SYS-3-INVMEMINT: Invalid memory action (malloc) at interrupt level

%SYS-2-MALLOCFAIL: Memory allocation of 52 bytes failed from 0x60298EF4, pool Processor, alignment 0




These messages most often show up in Cisco 4000 series routers when the routers are being reloaded. The workaround is to put the ATM interfaces in the shutdown state before reloading. [CSCdi62194]





%ATM-3-FAILCREATEVC: ATM failed to create VC(VCD=1011, VPI=0, VCI=262) on Interface ATM5/0, (Cause of the failure: Failed to have the driver to accept the VC) %AIP-3-AIPREJCMD: Interface ATM5/0, AIP driver rejected Teardown VC command (error code 0x8000)




[CSCdi62445]





Any release containing this bug should not be used in sites using LANE. The following releases are affected: 11.0(10.3), 11.1(5.3), 11.1(5.4), 11.2(0.23), and 11.2(0.24).


Note that for Release  11.0, only the Cisco 7000 images (gs7-) will be affected, as the Cisco  4500 and RSP-based systems do not run LANE using Release  11.0. [CSCdi68089]




 Caveats for Release 11.1(1) through 11.1(4)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(4). These caveats also apply to Releases 11.1(1) through 11.1(3) (unless otherwise noted).


 For more caveats of Release  11.1(4) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(5).


 AppleTalk



Note: For routers that are directly connected to a Phase 1 (non-Phase 2) router in compatibility mode, the appletalk proxy-nbp network zone command must be used. This will allow the router to convert the NBP FwdReq to NBP LkUp to the Phase 1 router. [CSCdi61668]




 Basic System Services



More than one problem can generate a similar error message and stack trace, which can make this problem hard to trace. See also CSCdi58999, CSCdi60952, and CSCdi60921. [CSCdi58658]





 DECnet



 IBM Connectivity



The work around is to define static peers.


Note: CSCdi61278 is a follow-on fix to this problem. [CSCdi58842]





d7c#conf mem
stun schema cnt offset 0 length 1 format hexidecimal
                                            ^
% Invalid input detected at '^' marker.




[CSCdi60992]





This bug fix is a follow-on fix to CSCdi58842. [CSCdi61278]





The symptom is that "dropped Routed protocol" messages are output when debug source-bridge error is enabled. [CSCdi62738]




 Interfaces and Bridging



The following three workarounds can be used:


no ipx pad-process-switched-packets




no ipx route-cache sse


ipx route-cache cbus




no ipx route-cache sse




[CSCdi42802]





 IP Routing Protocols



 ISO CLNS



 Novell IPX, XNS, and Apollo Domain



 VINES



 Wide-Area Networking



To cause links to disconnect earlier during a low-load or idle period, increase the load threshold. [CSCdi48263]





 Caveats for Release 11.1(1) through 11.1(3)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(3). These caveats also apply to Releases 11.1(1) and 11.1(2) (unless otherwise noted).


 For more caveats of Release  11.1(3) and earlier 11.1 releases, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(4).


 Access Server



 AppleTalk



 Basic System Services



 DECnet



 EXEC and Configuration Parser



 IBM Connectivity



The software fix for this problem passes UI frames through the border peer relay network. [CSCdi54796]





The low speed asynchronous/synchronous serial interface may drop SDLC frames with this configuration. The symptoms of this problem are poor performance and excessive Cyclic Redundancy Check (CRC) errors on the interface (as seen via the show interface command).


The fix for this problem requires: hardware version 00000002 and a software fix for this defect, which is incorporated into Cisco  IOS Release  11.0(9) and 11.1(4), and later.


All Cisco 2520, 2521, 2522, and 2523 routers manufactured before May 24, 1996 are subject to this problem.


To identify whether your router is affected, issue a show version command. The hardware revisions that are subject to the problem are "00000000" and "00000001." Hardware revision "00000002" contains the hardware fix that resolves this problem [CSCdi57040]:




cisco 2520 (68030) processor (revision E) with 4096K/2048K bytes of memory.
Processor board ID 02351913, with hardware revision 00000002





 Interfaces and Bridging



In addition to the hardware requirement, the fix for this bug that is in Release  11.0(8) and 11.1(4) and later releases requires that you allow a minimum of 15 seconds to elapse between OIR events. Removal of one interface counts as one event, and insertion of one interface counts as one event.


If your MIP hardware isn't at least hardware version 1.1, it will not EOIR or OIR correctly!


Failure to provide this time for the router to stabilize between OIR events can result in the reset performed for one event corrupting the reset performed for another event, which could require interfaces to be reconfigured or reinitialized manually. This reset requires even more time if additional channel-groups are defined within the router. The time between OIR events should be increased to as much as 30 seconds if three or more MIP cards are fully channelized in the router. While the corruption of this reset activity might occur only occasionally if OIR events are too closely timed, it is mandatory to allow the correct interval to guarantee the benefits of EOIR/OIR. [CSCdi46137]





For example, change:


access-list 116 permit ip any any
access-list 116 permit tcp any any gt 1023
access-list 116 permit tcp any any eq smtp


to:


access-list 116 permit ip any any


[CSCdi50886]





 IP Routing Protocols



 ISO CLNS



A workaround is to either disable IS-IS before removing the static route or enable IS-IS on the interface before removing the static route. [CSCdi56815]





A workaround is to filter out the ESH packets using the clns adjacency-filter es configuration command in conjunction with an appropriate filter set (which should specify a wildcard [**], in the last byte of the address). [CSCdi58621]




 Novell IPX, XNS, and Apollo Domain



 Protocol Translation



 Wide-Area Networking



In addition, when the serial line is configured to be frame-relay intf-type dce or frame-relay intf-type nni, if a frame-relay intf-type command is entered after the desired PVCs have been configured, then the router will fail to send the correct LMI Full Status message. [CSCdi52339]





%ATM-4-MTUCALLMISMATCH: Incoming call has mismatched maximum transmission unit




To workaround, reconfigure the remote device with the correct SDU size. [CSCdi57676]




 Caveats for Release 11.1(1) through 11.1(2)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(2). These caveats also apply to Release  11.1(1) (unless otherwise noted).


 For more caveats of Releases 11.1(2) and 11.1(1), see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(3).


 Access Server



 AppleTalk



 Basic System Services



 IBM Connectivity



DLSW:CPUHOG in CLS background, PC=0x60549f3c




Because the CPU is being occupied by the CLS background process for a period of time, protocols that involve polling may lose their connections because of poll starvation. [CSCdi52382]





The workaround is to remove the source-bridge command from the Token Ring interface and configure it back in. [CSCdi53954]





 Interfaces and Bridging



 IP Routing Protocols



 ISO CLNS



 Novell IPX, XNS, and Apollo Domain



 Wide-Area Networking



 Caveats for Release 11.1(1)


 This section describes caveats (possibly unexpected behavior) of Cisco  IOS Release  11.1(1). For more Release  11.1(1) caveats, see all the preceding caveat sections.


 Only serious caveats are described in these release notes. For the complete list of caveats against this release, access CCO or use the Documentation CD-ROM as described in the sections "Cisco Connection Online" and "Documentation CD-ROM" at the end of this document.


 All the caveats listed in this section are resolved in Release  11.1(2).


 Access Server



 Basic System Services



A workaround is to disable fast switching of IP multicasting, or fast switching of SRB fast explorers by using the no source explorer-fastswitch command. Another possible workaround is to remove or add an IP card, particularly of a different media type. [CSCdi45887]





 DECnet



 IBM Connectivity



 Interfaces and Bridging



 IP Routing Protocols



 ISO CLNS



 Novell IPX, XNS, and Apollo Domain



Clients on LANs with no server can connect correctly, because the router answers the GetNearestServer request. However, whenever a Novell server resides on the same LAN as the client, the client will not be able to connect to any remote services.


Use the show ipx servers command to determine whether any SAPs are being seen with zero hop count from the neighboring router. [CSCdi46488]





 TCP/IP Host-Mode Services



 VINES



 Wide-Area Networking



A possible workaround is to set the dialer idle-timeout value on the BRI routers connected to NET3 switches higher than the timeout value of the other router or routers connecting via ISDN. This workaround assumes the other router or routers do not have BRIs connected to NET3 switches, because they would have the same problem. This workaround also requires knowledge of the dialer idle-timeout value configured on the other router or routers.


The problem does not occur if the call hangup is initiated by the ISDN network rather than the BRI router connected to a NET3 switch.


Releases  11.0(2.1), 10.3(6.1) and 10.2(8.5) were the first software versions to exhibit the problem. [CSCdi46668]





To prevent this behavior, remove the cause of the line errors or increase the hold-queue size. [CSCdi48424]





If you choose to continue to use Cisco  IOS Release  11.0(5), Release  11.1(1) or earlier releases, the Catalyst  5000 requires ATM software Release  1.1. [CSCdi49790]





If, however, the original interface comes back up before the backup connection is complete, the floating static route will have been removed and a neighbor route will be added to the peer address. This route will carry routing updates to the peer over the backup connection and thus reset the idle timeout with each packet. As a result, the backup interface will never disconnect. This behavior was added with Release  11.0(3). [CSCdi50489]





 Microcode Software


 For Cisco 7000 and 7500 series platforms, microcode software images are bundled with the Release  11.1 system software images (features sets). The only exceptions are the Channel Interface Processor (CIP) microcode and the Versatile Interface Processor (VIP) microcode. CIP microcode is unbundled in all system software images. VIP and VIP2 microcode is contained only in feature sets that have "VIP" in the feature set name.


 Bundling eliminates the need to store separate microcode images. When the router starts, the system software unpacks the microcode software bundle and loads the proper software onto all the interface processor boards.


 Table 16 lists the microcode versions bundled into Release  11.1(17) software images for the Cisco  7000 series platforms.


 Table 17 lists the microcode versions bundled into Release  11.1(17) software images for the Cisco  7500 series platforms.



Note For the Cisco  7000 series, all boards must use the Level 10 (or greater) microcode that is bundled (except CIP) with the system image.








Table 16: Current Microcode Versions for the Cisco 7000 Series


Processor or Module
Current Bundled Microcode Version
Minimum Version Required



 AIP (ATM Interface Processor)


 10.25


 10.12




 EIP (Ethernet Interface Processor)


 10.2


 10.1




 FEIP (Fast Ethernet Interface Processor)


 10.7


 10.2




 FIP (FDDI Interface Processor)


 10.2


 10.2




 FSIP (Fast Serial Interface Processor)


 10.19


 10.12




 HIP (HSSI Interface Processor)


 10.3


 10.2




 MIP (MultiChannel Interface Processor)


 12.2


 11.4




 SP (Switch Processor)


 11.15


 11.14




 SSP (Silicon Switch Processor)


 11.15


 11.14




 TRIP (Token Ring Interface Processor)


 10.4


 10.3




 VIP (Versatile Interface Processor)1


 21.40


 21.9








1VIP microcode resides within the Cisco  IOS software; it is not "bundled" in.











Table 17: Current Microcode Versions for the Cisco 7500 Series


Processor or Module
Current Bundled RSP Microcode Version
Minimum Version Required



 AIP (ATM Interface Processor)


 20.18


 20.5




 EIP (Ethernet Interface Processor)


 20.6


 20.1




 FEIP (Fast Ethernet Interface Processor)


 20.6


 20.1




 FIP (FDDI Interface Processor)


 20.1


 20.1




 FSIP (Fast Serial Interface Processor)


 20.8


 20.1




 HIP (HSSI Interface Processor)


 20.2


 20.0




 MIP (MultiChannel Interface Processor)


 22.2


 20.3




 POSIP (Packet over SONET OC-3 Interface Processor)


 20.0


 20.0




 RSP2 (Route Switch Processor)1


 N/A


 200.0




 TRIP (Token Ring Interface Processor)


 20.1


 20.0




 VIP (Versatile Interface Processor)1


 21.40


 21.9




 VIP2 (second-generation Versatile Interface Processor)1


 21.40


 21.40








1RSP2, VIP, and VIP2 microcode reside within the Cisco  IOS software; they are not "bundled" in.







Note RSP2 microcode was introduced in Release  11.1(2).




Note POSIP and VIP2 microcode were introduced in Release  11.1(5).



 Channel Interface Processor (CIP) Microcode


 Beginning with Cisco  IOS Release  11.1, the CIP microcode is no longer bundled with the Cisco  IOS software image.


 Also note that to use the IBM channel attach features in Cisco  IOS Release  11.1, you must have Flash memory installed on the Route Processor (RP) card and 8 MB RAM installed on your CIP card.


 See the "Important Notes" section for more information about CIP microcode.


 Microcode Revision History (for Cisco  7000 Series Platforms)


 This section describes each revision of microcode for Cisco  7000 series routers using a route processor/silicon switch processor (RP/SSP) or route processor/switch processor (RP/SP) combination. The descriptions list the caveats that were fixed in each microcode revision. This section does not describe RSP microcode.For descriptions of each revision of RSP microcode, which is used with Cisco  7500 series routers and Cisco  7000 series routers using an RSP7000, see the next section, "Route Switch Processor (RSP) Microcode Revision History."


 ATM Interface Processor (AIP) Microcode Revision Summary


 AIP Microcode Version 10.13


 Modification


 AIP Microcode Version 10.13 fixes the following:



 AIP Microcode Version 10.14


 Modifications


 AIP Microcode Version 10.14 fixes the following:



 AIP Microcode Version 10.15


 Modification


 AIP Microcode Version 10.15 fixes the following:



%ATM-3-FAILCREATEVC: ATM failed to create VC(VCD=1011, VPI=0, VCI=262) on Interface ATM5/0, (Cause of the failure: Failed to have the driver to accept the VC) %AIP-3-AIPREJCMD: Interface ATM5/0, AIP driver rejected Teardown VC command (error code 0x8000)



 AIP Microcode Version 10.16


 Modifications


 AIP Microcode Version 10.16 fixes the following:



A workaround is either to downgrade the AIP microcode to aip20-6 or to upgrade the AIP microcode to rsp_aip205-5, or aip20-9 when available. A short term workaround is clear int atm 5/0 on the transmit side. [CSCdi67812]


The same problem applies for aip10-15 on RP based platforms.





 AIP Microcode Version 10.17


 Modifications


 AIP Microcode Version 10.17 fixes the following:



 AIP Microcode Version 10.18


 Modification


 AIP Microcode Version 10.18 fixes the following:



 AIP Microcode Version 10.19


 Modification


 AIP Microcode Version 10.19 fixes the following:



 AIP Microcode Version 10.20


 Modification


 AIP Microcode Version 10.20 fixes the following:



 AIP Microcode Version 10.21


 Modification


 AIP Microcode Version 10.21 fixes the following:



%AIP-3-AIPREJCMD with error code 0x8000


%SYS-3-CPUHOG


[CSCdj20667]




 AIP Microcode Version 10.22


 Modification


 AIP Microcode Version 10.22 fixes the following:



 AIP Microcode Version 10.23


 Modification


 AIP Microcode Version 10.23 fixes the following:



 AIP Microcode Version 10.24


 Modification


 AIP Microcode Version 10.24 fixes the following:



 AIP Microcode Version 10.25


 Modification


 AIP Microcode Version 10.25 fixes the following:



 Fast Ethernet Interface Processor (FEIP) Microcode Revision Summary


 FEIP Microcode Version 10.3


 Modification


 FEIP Microcode Version 10.3 fixes the following:



 FEIP Microcode Version 10.4


 Modifications


 FEIP Microcode Version 10.4 fixes the following:



 FEIP Microcode Version 10.5


 Modifications


 FEIP Microcode Version 10.5 fixes the following:



 FEIP Microcode Version 10.6


 Modifications


 FEIP Microcode Version 10.6 fixes the following:



 FEIP Microcode Version 10.7


 Modification


 FEIP Microcode Version 10.7 fixes the following:



 Fast Serial Interface Processor (FSIP) Microcode Revision Summary


 FSIP Microcode Version 10.13


 Modification


 FSIP Microcode Version 10.13 fixes the following:



 FSIP Microcode Version 10.14


 FSIP Microcode Version 10.14 was never released.


 FSIP Microcode Version 10.15


 FSIP Microcode Version 10.15 was never released.


 FSIP Microcode Version 10.16


 Modifications


 FSIP Microcode Version 10.16 fixes the following:



 FSIP Microcode Version 10.17


 Modification


 FSIP Microcode Version 10.17 fixes the following:



 FSIP Microcode Version 10.18


 Modification


 FSIP Microcode Version 10.18 fixes the following:



 FSIP Microcode Version 10.19


 Modification


 FSIP Microcode Version 10.19 fixes the following:



 HSSI Interface Processor (HIP) Microcode Revision Summary


 HIP Microcode Version 20.1


 Modification


 HIP Microcode Version 20.1 fixes the following:



 HIP Microcode Version 20.2


 Modification


 HIP Microcode Version 20.2 fixes the following:



 MultiChannel Interface Processor (MIP) Microcode Revision Summary


 MIP Microcode Version 12.0


 Modification


 MIP Microcode Version 12.0 fixes the following:



 MIP Microcode Version 12.1


 Modification


 MIP Microcode Version 12.1 fixes the following:



 MIP Microcode Version 12.2


 Modifications


 MIP Microcode Version 12.2 fixes the following:



 Switch Processor (SP) Microcode Revision Summary


 SP Microcode Version 11.15


 Modification


 SP Microcode Version 11.15 fixes the following:



The following three workarounds can be used:


no ipx pad-process-switched-packets




no ipx route-cache sse


ipx route-cache cbus




no ipx route-cache sse




[CSCdi42802], [CSCdi45139], [CSCdi46156]




 Silicon Switch Processor (SSP) Microcode Revision Summary


 SSP Microcode Version 11.15


 Modification


 SSP Microcode Version 11.15 fixes the following:



The following three workarounds can be used:


ipx route-cache cbus




[CSCdi42802], [CSCdi45139], [CSCdi46156]




 Token Ring Interface Processor (TRIP) Microcode Revision Summary


 TRIP Microcode Version 10.4


 Modification


 TRIP Microcode Version 10.4 fixes the following:



 Versatile Interface Processor (VIP) Microcode Revision Summary


 VIP Microcode Version 20.18


 Modifications


 VIP Microcode Version 20.18 fixes the following:



 VIP Microcode Version 20.23


 The next major release of VIP microcode after Version 20.18 is Version 20.23.


 For modifications related to VIP, refer to the section "Caveats for Release 11.1(1) through 11.1(2)" earlier in this document.


 VIP Microcode Version 20.31


 The next major release of VIP microcode after Version 20.23 is Version 20.31.


 For modifications related to VIP, refer to the section "Caveats for Release 11.1(1) through 11.1(3)" earlier in this document.


 VIP Microcode Version 20.40


 The next major release of VIP microcode after Version 20.31 is Version 20.40.


 For modifications related to VIP, refer to the section "Caveats for Release 11.1(1) through 11.1(4)" earlier in this document.


 Route Switch Processor (RSP) Microcode Revision History


 This section describes each revision of RSP microcode, which is used with Cisco  7500 series routers and Cisco  7000 series routers using an RSP7000. The descriptions list the caveats that were fixed in each microcode revision.


 For descriptions of each revision of microcode for Cisco  7000 series routers using a route processor/silicon switch processor (RP/SSP) or route processor/switch processor (RP/SP) combination, see the previous section, "Microcode Revision History (for Cisco 7000 Series Platforms)."


 ATM Interface Processor (AIP) Microcode Revision Summary


 AIP Microcode Version 20.6


 Modification


 AIP Microcode Version 20.6 fixes the following:



 AIP Microcode Version 20.7


 Modifications


 AIP Microcode Version 20.7 fixes the following:



 AIP Microcode Version 20.8


 Modification


 AIP Microcode Version 20.8 fixes the following:



%ATM-3-FAILCREATEVC: ATM failed to create VC(VCD=1011, VPI=0, VCI=262) on Interface ATM5/0, (Cause of the failure: Failed to have the driver to accept the VC) %AIP-3-AIPREJCMD: Interface ATM5/0, AIP driver rejected Teardown VC command (error code 0x8000)



 AIP Microcode Version 20.9


 Modifications


 AIP Microcode Version 20.9 fixes the following:



A workaround is either to downgrade the AIP microcode to aip20-6 or to upgrade the AIP microcode to rsp_aip205-5, or aip20-9 when available. A short term workaround is clear int atm 5/0 on the transmit side. [CSCdi67812]


The same problem applies for aip10-15 on RP-based platforms.





 AIP Microcode Version 20.10


 Modifications


 AIP Microcode Version 20.10 fixes the following:



 AIP Microcode Version 20.11


 Modification


 AIP Microcode Version 20.11 fixes the following:



 AIP Microcode Version 20.12


 Modification


 AIP Microcode Version 20.12 fixes the following:



 AIP Microcode Version 20.13


 Modification


 AIP Microcode Version 20.13 fixes the following:



 AIP Microcode Version 20.14


 Modification


 AIP Microcode Version 20.14 fixes the following:



%AIP-3-AIPREJCMD with error code 0x8000


%SYS-3-CPUHOG


[CSCdj20667]




 AIP Microcode Version 20.15


 Modification


 AIP Microcode Version 20.15 fixes the following:



 AIP Microcode Version 20.16


 Modification


 AIP Microcode Version 20.16 fixes the following:



 AIP Microcode Version 20.17


 Modification


 AIP Microcode Version 20.17 fixes the following:



 AIP Microcode Version 20.18


 Modification


 AIP Microcode Version 20.18 fixes the following:



 Ethernet Interface Processor (EIP) Microcode Revision Summary


 EIP Microcode Version 20.2


 Modification


 EIP Microcode Version 20.2 fixes the following:



 EIP Microcode Version 20.3


 Modification


 EIP Microcode Version 20.3 fixes the following:



 EIP Microcode Version 20.4


 Modification


 EIP Microcode Version 20.4 fixes the following:



 EIP Microcode Version 20.5


 Modification


 EIP Microcode Version 20.5 fixes the following:



 EIP Microcode Version 20.6


 Modification


 EIP Microcode Version 20.6 fixes the following:



 Fast Ethernet Interface Processor (FEIP) Microcode Revision Summary


 FEIP Microcode Version 20.2


 Modification


 FEIP Microcode Version 20.2 fixes the following:



 FEIP Microcode Version 20.3


 Modifications


 FEIP Microcode Version 20.3 fixes the following:



 FEIP Microcode Version 20.4


 Modifications


 FEIP Microcode Version 20.4 fixes the following:



 FEIP Microcode Version 20.5


 Modifications


 FEIP Microcode Version 20.5 fixes the following:



 FEIP Microcode Version 20.6


 Modification


 FEIP Microcode Version 20.6 fixes the following:



 Fast Serial Interface Processor (FSIP) Microcode Revision Summary


 FSIP Microcode Version 20.2


 Modifications


 FSIP Microcode Version 20.2 fixes the following:



 FSIP Microcode Version 20.3


 Modifications


 FSIP Microcode Version 20.3 fixes the following:



Serialx/y is down, line protocol is down
  Hardware is cyBus Serial
.
.
.
  0 output buffer failures, 0 output buffers swapped out
    0 carrier transitions
    RTS up, CTS up, DTR up, DCD up, DSR up




The serial interface will stay down if the remote side toggles. [CSCdi57573]





 FSIP Microcode Version 20.4


 Modification


 FSIP Microcode Version 20.4 fixes the following:



 FSIP Microcode Version 20.5


 Modifications


 FSIP Microcode Version 20.5 fixes the following:



 FSIP Microcode Version 20.6


 Modification


 FSIP Microcode Version 20.6 fixes the following:



 FSIP Microcode Version 20.7


 Modification


 FSIP Microcode Version 20.7 fixes the following:



 FSIP Microcode Version 20.8


 Modification


 FSIP Microcode Version 20.8 fixes the following:



 HSSI Interface Processor (HIP) Microcode Revision Summary


 HIP Microcode Version 20.1


 Modification


 HIP Microcode Version 20.1 fixes the following:



 HIP Microcode Version 20.2


 Modification


 HIP Microcode Version 20.2 fixes the following:



 MultiChannel Interface Processor (MIP) Microcode Revision Summary


 MIP Microcode Version 22.0


 Modification


 MIP Microcode Version 22.0 fixes the following:



 MIP Microcode Version 22.1


 Modification


 MIP Microcode Version 22.1 fixes the following:



 MIP Microcode Version 22.2


 Modifications


 MIP Microcode Version 22.2 fixes the following:



 Route Switch Processor 2 (RSP2) Microcode Revision Summary


 The next major release of RSP2 microcode after Version 200.0 is Version 20.0.


 For modifications related to RSP2, refer to the section "Caveats for Release 11.1(1) through 11.1(4)" earlier in this document.



Note The initial release of RSP2 microcode was Version 200.0, in Cisco  IOS Release  11.1(2).



 Token Ring Interface Processor (TRIP) Microcode Revision Summary


 TRIP Microcode Version 20.1


 Modification


 TRIP Microcode Version 20.1 fixes the following:



 TRIP Microcode Version 20.2


 Modification


 TRIP Microcode Version 20.2 fixes the following:



 Versatile Interface Processor (VIP) Microcode Revision Summary


 The VIP microcode for the RSP is the same as the Cisco  7000 VIP microcode.


 Cisco Connection Online


 Cisco Connection Online (CCO) is Cisco Systems' primary, real-time support channel. Maintenance customers and partners can self-register on CCO to obtain additional information and services.


 Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-added services to Cisco's customers and business partners. CCO services include product information, product documentation, software updates, release notes, technical tips, the Bug Navigator, configuration notes, brochures, descriptions of service offerings, and download access to public and authorized files.


 CCO serves a wide variety of users through two interfaces that are updated and enhanced simultaneously: a character-based version and a multimedia version that resides on the World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit, Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over lower bandwidths. The WWW version of CCO provides richly formatted documents with photographs, figures, graphics, and video, as well as hyperlinks to related information.


 You can access CCO in the following ways:



 For a copy of CCO's Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com.



Note If you are a network administrator and need personal technical assistance with a Cisco product that is under warranty or covered by a maintenance contract, contact Cisco's Technical Assistance Center (TAC) at 800  553-2447, 408  526-7209, or tac@cisco.com. To obtain general information about Cisco Systems, Cisco products, or upgrades, contact 800  553-6387, 408  526-7208, or cs-rep@cisco.com.



 Documentation CD-ROM


 Cisco documentation and additional literature are available in a CD-ROM package, which ships with your product. The Documentation CD-ROM, a member of the Cisco Connection Family, is updated monthly. Therefore, it might be more current than printed documentation. To order additional copies of the Documentation CD-ROM, contact your local sales representative or call customer service. The CD-ROM package is available as a single package or as an annual subscription. You can also access Cisco documentation on the World Wide Web at http://www.cisco.com,  http://www-china.cisco.com,  or http://www-europe.cisco.com.


 If you are reading Cisco product documentation on the World Wide Web, you can submit comments electronically. Click Feedback in the toolbar and select Documentation. After you complete the form, click Submit to send it to Cisco. We appreciate your comments.












hometocprevnextglossaryfeedbacksearchhelp






Copyright 1989-1999©Cisco Systems Inc.
